22_BNO-0-0-1/133_NE

Active

Huber+Suhner, Inc.

RF CONNECTOR, 1 CONTACT(S), FEMALE, PANEL MOUNT, JACK, ROHS COMPLIANT

Search across all available documentation for this part.

Active

Huber+Suhner, Inc.

RF CONNECTOR, 1 CONTACT(S), FEMALE, PANEL MOUNT, JACK, ROHS COMPLIANT

Technical Specifications

Parameters and characteristics for this part

Specification	22_BNO-0-0-1/133_NE

Body Finish	White Bronze
Body Material	Brass
Center Contact Material	Brass, Beryllium Copper
Center Contact Plating	Gold
Connector Style	BNO
Connector Type	Female Socket, Jack
Contact Termination	Solder
Dielectric Material	Ethylenterafluorineethylene (ETFE)
Fastening Type	Bayonet Lock
Frequency - Max [Max]	200 MHz
Housing Color	Silver
Mounting Feature	Bulkhead - Rear Side Nut
Number of Ports	1
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-50 °C
Shield Termination	Solder

Part	Body Finish	Fastening Type	Mounting Feature	Connector Type	Center Contact Material	Contact Termination	Frequency - Max [Max]	Number of Ports	Housing Color	Shield Termination	Operating Temperature [Min]	Operating Temperature [Max]	Connector Style	Dielectric Material	Body Material	Center Contact Plating
Huber+Suhner, Inc. 22_BNO-0-0-2/133_NE	White Bronze	Bayonet Lock	Bulkhead - Rear Side Nut	Female Socket Jack	Beryllium Copper Brass	Solder	200 MHz	1	Silver	Solder	-50 °C	125 °C	BNO	Ethylenterafluorineethylene (ETFE)	Brass	Gold
Huber+Suhner, Inc. 22_BNO-0-0-1/133_NE	White Bronze	Bayonet Lock	Bulkhead - Rear Side Nut	Female Socket Jack	Beryllium Copper Brass	Solder	200 MHz	1	Silver	Solder	-50 °C	125 °C	BNO	Ethylenterafluorineethylene (ETFE)	Brass	Gold

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	10	$ 56.80

General part information

BNO Connector Jack, Female Socket Panel Mount Solder
