ABB-04BFFC-LL7SP0

Active

Amphenol LTW

CERES, STANDARD SIZE, PLASTIC, 10A, 04 PINS, FEMALE CONNECTOR, FEMALE CONTACT, STRAIGHT, 2 POINTS LOCK, CRIMP, FIELD INSTALLABLE

Search across all available documentation for this part.

Active

Amphenol LTW

CERES, STANDARD SIZE, PLASTIC, 10A, 04 PINS, FEMALE CONNECTOR, FEMALE CONTACT, STRAIGHT, 2 POINTS LOCK, CRIMP, FIELD INSTALLABLE

Technical Specifications

Parameters and characteristics for this part

Specification	ABB-04BFFC-LL7SP0

Backshell Material, Plating	Nylon, Polyamide (PA), Glass Filled
Cable Opening [Max] [custom]	0.236 in
Cable Opening [Max] [custom]	6 mm
Cable Opening [Min] [custom]	5 mm
Cable Opening [Min] [custom]	0.197 in
Color	Black
Connector Type	Female Sockets, Plug
Contact Finish - Mating	Gold
Contact Material	Copper Alloy
Current Rating (Amps)	10 A
Features	Coupling Nut, Backshell
Ingress Protection	IP67 - Dust Tight, Waterproof
Insert Material	Polyamide (PA), Nylon, Glass Filled
Material Flammability Rating	UL94 V-0
Mounting Type	Free Hanging (In-Line)
Number of Positions	4
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Orientation	Keyed
Primary Material	Plastic
Shell Material	Nylon, Glass Filled, Polyamide (PA)
Shell Size - Insert	B
Shielding	Unshielded
Termination	Crimp
Voltage Rating	250 VDC

Part	Backshell Material, Plating	Shell Material	Current Rating (Amps)	Contact Finish - Mating	Material Flammability Rating	Insert Material	Features	Color	Mounting Type	Cable Opening [Max] [custom]	Cable Opening [Min] [custom]	Cable Opening [Max] [custom]	Cable Opening [Min] [custom]	Shell Size - Insert	Primary Material	Contact Material	Termination	Connector Type	Orientation	Voltage Rating	Number of Positions	Ingress Protection	Operating Temperature [Min]	Operating Temperature [Max]	Shielding
Amphenol LTW ABB-04BFFC-SL7MP0	Glass Filled Nylon Polyamide (PA)	Glass Filled Nylon Polyamide (PA)	10 A	Gold	UL94 V-0	Polyamide (PA) Nylon Glass Filled	Backshell	Black	Free Hanging (In-Line)	8 mm	6 mm	0.315 in	0.236 in	B	Plastic	Copper Alloy	Crimp	Female Sockets Plug	Keyed	250 VDC	4	IP67 - Dust Tight Waterproof	-40 °C	105 ░C	Unshielded
Amphenol LTW ABB-04BFFC-SL7AP0	Glass Filled Nylon Polyamide (PA)	Glass Filled Nylon Polyamide (PA)	10 A	Gold	UL94 V-0	Polyamide (PA) Nylon Glass Filled	Backshell Coupling Nut	Black	Free Hanging (In-Line)					B	Plastic	Copper Alloy	Crimp	Female Sockets Plug	Keyed	300 VDC	4	IP67 - Dust Tight Waterproof	-40 °C	105 ░C	Unshielded
Amphenol LTW ABB-04BFFC-LL7SP0	Glass Filled Nylon Polyamide (PA)	Glass Filled Nylon Polyamide (PA)	10 A	Gold	UL94 V-0	Polyamide (PA) Nylon Glass Filled	Backshell Coupling Nut	Black	Free Hanging (In-Line)	6 mm	5 mm	0.236 in	0.197 in	B	Plastic	Copper Alloy	Crimp	Female Sockets Plug	Keyed	250 VDC	4	IP67 - Dust Tight Waterproof	-40 °C	105 ░C	Unshielded

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

4 (Data) Position Circular Connector Plug, Female Sockets Crimp
