TMP 15515C
ActiveTraco Power
AC/DC POWER SUPPLY TRIPLE-OUT 5V/15V/-15V 2A/0.15A/0.15A 15W 9-PIN
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
TMP 15515C
ActiveTraco Power
AC/DC POWER SUPPLY TRIPLE-OUT 5V/15V/-15V 2A/0.15A/0.15A 15W 9-PIN
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | TMP 15515C |
|---|---|
| Applications | Industrial, ITE (Commercial) |
| Approval Agency | cULus, CE, cURus, CB |
| Current - Output 1 | 2 A |
| Current - Output 2 | 150 mA |
| Current - Output 3 | 150 mA |
| Efficiency | 74 % |
| Features | Adjustable Output, Universal Input |
| Minimum Load Required | True |
| Mounting Type | Chassis Mount |
| Number of Outputs | 3 |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -25 °C |
| Power (Watts) | 15 W |
| Size / Dimension [x] | 96 mm |
| Size / Dimension [x] | 3.78 " |
| Size / Dimension [y] | 2.13 in |
| Size / Dimension [y] | 54.1 mm |
| Size / Dimension [z] | 0.92 " |
| Size / Dimension [z] | 23.4 mm |
| Type | Enclosed |
| Voltage - Input [Max] | 370 VDC, 264 VAC |
| Voltage - Input [Min] | 85 VAC, 120 VDC |
| Voltage - Isolation | 3000 V |
| Voltage - Output 1 | 5 V |
| Voltage - Output 2 | 15 V |
| Voltage - Output 3 | -15 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
TMP 15515 Series
Enclosed AC DC Converters 3 Output 5V 15V -15V 85 ~ 264 VAC, 120 ~ 370 VDC Input
