5647-O

Active

BRADY

B689 5647-O WHT/GRN STYLE O

Search across all available documentation for this part.

Active

BRADY

B689 5647-O WHT/GRN STYLE O

Technical Specifications

Parameters and characteristics for this part

Specification	5647-O

Application Specifics	Water Fluids
Applications	General
Arrangement	Symbol and Text
Color - Background	Green
Color - Legend	White
Features	Water Resistant, Weather Resistant, Humidity Resistant, Chemical Resistant, UV Resistant, Abrasion Resistant
Language	English
Legend (Symbol Only)	Directional Arrow
Legend (Text)	Chilled Water Return
Length	8 in
Length	203.2 mm
Location	Outdoor
Material - Body	Plastic
Mounting Type	Snap On
Outside Pipe Diameter (Max) [Max] [diameter]	12.7 mm
Outside Pipe Diameter (Max) [Max] [diameter]	0.5 "
Outside Pipe Diameter (Min) [Min] [diameter]	1.375 in
Outside Pipe Diameter (Min) [Min] [diameter]	34.93 mm
Print Type	Pre-Printed
Shape	Rectangle
Width [y]	127 mm
Width [y]	5 in

Part	Location	Color - Legend	Legend (Symbol Only)	Mounting Type	Material - Body	Color - Background	Legend (Text)	Application Specifics	Features	Arrangement	Applications	Shape	Outside Pipe Diameter (Min) [Min] [diameter]	Outside Pipe Diameter (Min) [Min] [diameter]	Print Type	Outside Pipe Diameter (Max) [diameter]	Outside Pipe Diameter (Max) [diameter]	Language	Length	Length	Width [x]	Width [x]	Width	Outside Pipe Diameter (Min) [Min] [diameter]	Outside Pipe Diameter (Max) [Max] [diameter]	Outside Pipe Diameter (Max) [Max] [diameter]	Width [y]	Width [y]	Material	Label Size	Label Size	Color	Label Type
BRADY 5647-I	Outdoor	White	Directional Arrow	Snap On	Plastic	Green	Chilled Water Return	Directionality	Abrasion Resistant Chemical Resistant Humidity Resistant UV Resistant Water Resistant Weather Resistant	Symbol and Text	Pipe	Rectangle	2.375 in	60.33 mm	Pre-Printed	1.5 "	38.1 mm	English	9 "	228.6 mm	8 in	203.2 mm
BRADY 5647-II	Outdoor	White	Directional Arrow	Snap On	Plastic	Green	Chilled Water Return	Water Fluids	Chemical Resistant	Symbol and Text	Pipe	Rectangle	7.875 in	200.03 mm	Pre-Printed	2.5 "	63.5 mm	English	26 in	660.4 mm	12 in		304.8 mm
BRADY 5647-O	Outdoor	White	Directional Arrow	Snap On	Plastic	Green	Chilled Water Return	Water Fluids	Abrasion Resistant Chemical Resistant Humidity Resistant UV Resistant Water Resistant Weather Resistant	Symbol and Text	General	Rectangle	1.375 in		Pre-Printed			English	8 in	203.2 mm				34.93 mm	12.7 mm	0.5 "	127 mm	5 in
BRADY 5647-HPHV																													Polyester	4 in 24 in	101.6 mm 609.6 mm	White Legend Green Background	Chilled Water Return
