OSTTB021161

Active

On Shore Technology Inc.

TERM BLK 2POS TOP ENTRY 10MM PCB

Search across all available documentation for this part.

Active

On Shore Technology Inc.

TERM BLK 2POS TOP ENTRY 10MM PCB

Technical Specifications

Parameters and characteristics for this part

Specification	OSTTB021161

Clamp Material - Plating	Stainless, Steel
Contact Material - Plating [custom]	Brass
Current	16 A
Features	Interlocking (Side)
Housing Material	Polyamide (PA), Nylon
Mating Orientation	Vertical with Board
Mounting Type	Through Hole
Number of Levels	1
Operating Temperature [Max]	120 °C
Operating Temperature [Min]	-33 °C
Pitch [x]	0.394 in
Pitch [x]	10 mm
Positions Per Level	2
Screw Material - Plating	Steel, Galvanized - Chromate Plated
Screw Thread	M3
Torque - Screw	0.4 Nm
Torque - Screw	3.5 Lb-In
Wire Gauge [Max]	22 AWG
Wire Gauge [Min]	14 AWG
Wire Termination	Screw

Part	Screw Thread	Current	Pitch [x]	Pitch [x]	Mating Orientation	Mounting Type	Housing Material	Number of Levels	Contact Material - Plating [custom]	Wire Gauge [Min]	Wire Gauge [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Clamp Material - Plating	Screw Material - Plating	Wire Termination	Color	Features	Torque - Screw	Torque - Screw	Positions Per Level	Contact Material - Plating [custom]
On Shore Technology Inc. OSTTB020161	M3	16 A	5 mm	0.197 in	Vertical with Board	Through Hole	Thermoplastic	1	Tin Plated	14 AWG	22 AWG	-30 ░C	105 ░C	Stainless Steel	Steel Zinc Plated	Screw - Leaf Spring Wire Guard	Blue	Interlocking (Side)	0.3 Nm	2.6 Lb-In	2
On Shore Technology Inc. OSTTB021161	M3	16 A	10 mm	0.394 in	Vertical with Board	Through Hole	Polyamide (PA) Nylon	1		14 AWG	22 AWG	-33 °C	120 °C	Stainless Steel	Steel Galvanized - Chromate Plated	Screw		Interlocking (Side)	0.4 Nm	3.5 Lb-In	2	Brass

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	136	$ 0.33

General part information

2 Position Wire to Board Terminal Block Vertical with Board 0.394" (10.00mm) Through Hole
