20HV24B473MN

Active

KEMET

CERAMIC CAPACITOR, CERAMIC, 2000V, 20% +TOL, 20% -TOL, X7R, 15% TC, 0.047UF, THROUGH HOLE MOUNT, 5727, RADIAL LEADED

Search across all available documentation for this part.

Active

KEMET

CERAMIC CAPACITOR, CERAMIC, 2000V, 20% +TOL, 20% -TOL, X7R, 15% TC, 0.047UF, THROUGH HOLE MOUNT, 5727, RADIAL LEADED

Technical Specifications

Parameters and characteristics for this part

Part	Applications	Package / Case	Temperature Coefficient	Features	Mounting Type	Voltage - Rated	Voltage - Rated	Operating Temperature [Min]	Operating Temperature [Max]	Lead Style	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Lead Spacing	Lead Spacing	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Tolerance
KEMET 20HV24B473MN	SMPS Filtering	Radial	X7R	High Voltage	Through Hole	2 kV	2000 V	-55 °C	125 °C	Straight	0.57 in	14.48 mm	0.271 "	6.89 mm	12.06 mm	0.475 in	12.7 mm	0.5 in	20 %

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

0.047 µF ±20% 2000V (2kV) Ceramic Capacitor X7R Radial
