PPPC401LGBN-RC

Active

Sullins Connector Solutions

2.54MM 3A SINGLE ROW GOLD 40P -40℃~+105℃ 250V RIGHT-ANGLE 2.54MM PUSH-PULL,P=2.54MM FEMALE HEADERS ROHS

Search across all available documentation for this part.

Active

Sullins Connector Solutions

2.54MM 3A SINGLE ROW GOLD 40P -40℃~+105℃ 250V RIGHT-ANGLE 2.54MM PUSH-PULL,P=2.54MM FEMALE HEADERS ROHS

Technical Specifications

Parameters and characteristics for this part

Specification	PPPC401LGBN-RC

Connector Type	Header
Contact Finish - Mating	Gold
Contact Finish - Post	Gold
Contact Finish Thickness - Mating	Flash
Contact Finish Thickness - Post	Flash
Contact Length - Post	3.15 mm
Contact Length - Post	0.124 "
Contact Material	Phosphor Bronze
Contact Shape	Square
Contact Type	Female Socket
Current Rating (Amps)	3 A
Fastening Type	Push-Pull
Insulation Color	Black
Insulation Height	0.1 in
Insulation Height	2.54 mm
Insulation Material	Polyester
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole, Right Angle
Number of Positions	40
Number of Positions Loaded	All
Number of Rows	1
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Pitch - Mating	0.1 in
Pitch - Mating	2.54 mm
Termination	Solder
Voltage Rating	250 VDC

Part	Mounting Type	Voltage Rating	Contact Type	Insulation Color	Contact Finish - Post	Contact Material	Number of Positions	Contact Length - Post	Contact Length - Post	Connector Type	Operating Temperature [Min]	Operating Temperature [Max]	Contact Finish - Mating	Number of Rows	Material Flammability Rating	Contact Shape	Pitch - Mating	Pitch - Mating	Fastening Type	Termination	Current Rating (Amps)	Insulation Material	Contact Finish Thickness - Mating	Contact Finish Thickness - Post	Insulation Height	Insulation Height	Number of Positions Loaded
Sullins Connector Solutions PPPC401LGBN	Through Hole Right Angle	250 VDC	Female Socket	Black	Gold	Phosphor Bronze	40	3.15 mm	0.124 "	Header	-40 °C	105 ░C	Gold	1	UL94 V-0	Square	0.1 in	2.54 mm	Push-Pull	Solder	3 A	Polyester	Flash	Flash	0.1 in	2.54 mm	All
Sullins Connector Solutions PPPC401LGBN-RC	Through Hole Right Angle	250 VDC	Female Socket	Black	Gold	Phosphor Bronze	40	3.15 mm	0.124 "	Header	-40 °C	105 ░C	Gold	1	UL94 V-0	Square	0.1 in	2.54 mm	Push-Pull	Solder	3 A	Polyester	Flash	Flash	0.1 in	2.54 mm	All

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

40 Position Header Connector 0.100" (2.54mm) Through Hole, Right Angle Gold
