GF0771M

Active

CUI Devices

SPEAKER 8OHM 1W TOP PORT 90DB

Search across all available documentation for this part.

Active

CUI Devices

SPEAKER 8OHM 1W TOP PORT 90DB

Technical Specifications

Parameters and characteristics for this part

Specification	GF0771M

Efficiency - dBA	90 dBA
Efficiency - Testing	1 mW/100mm
Efficiency - Type	Sound Pressure Level (SPL)
Frequency - Self Resonant	280 Hz
Frequency Range [Max]	11 kHz
Frequency Range [Min]	280 Hz
Height - Seated (Max) [Max] [z]	0.945 in
Height - Seated (Max) [Max] [z]	24 mm
Impedance	8 Ohms
Material - Cone	Polyester, Polyethylene Terephthalate (PET)
Material - Magnet	Ferrite
Port Location	Top
Power - Max [Max]	2 W
Power - Rated	1 W
Shape	Round
Size / Dimension [diameter]	77 mm
Size / Dimension [diameter]	3.032 in
Technology	Magnetic
Termination	Solder Eyelet(s)
Type	General Purpose

Part	Material - Cone	Port Location	Type	Efficiency - Testing	Frequency Range [Max]	Frequency Range [Min]	Impedance	Frequency - Self Resonant	Power - Rated	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Efficiency - dBA	Shape	Size / Dimension [diameter]	Size / Dimension [diameter]	Termination	Material - Magnet	Efficiency - Type	Power - Max [Max]	Technology
CUI Devices GF0771M	Polyester Polyethylene Terephthalate (PET)	Top	General Purpose	1 mW/100mm	11 kHz	280 Hz	8 Ohms	280 Hz	1 W	0.945 in	24 mm	90 dBA	Round	77 mm	3.032 in	Solder Eyelet(s)	Ferrite	Sound Pressure Level (SPL)	2 W	Magnetic

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1000	$ 3.14

General part information

8 Ohms General Purpose Speaker 1 W 280 Hz ~ 11 kHz Top Round
