VX7809-1000R
ActiveCUI Inc.
DC DC CONVERTER 9V 9W
Deep-Dive with AI
Search across all available documentation for this part.
VX7809-1000R
ActiveCUI Inc.
DC DC CONVERTER 9V 9W
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | VX7809-1000R |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | EN, CB Scheme, UL, IEC |
| Current - Output (Max) [Max] | 1 A |
| Efficiency | 95 % |
| Mounting Type | Through Hole, Right Angle |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 3-SIP Module |
| Power (Watts) | 9 W |
| Size / Dimension [x] | 17.5 mm |
| Size / Dimension [x] | 0.69 in |
| Size / Dimension [y] | 0.45 in |
| Size / Dimension [y] | 11.5 mm |
| Size / Dimension [z] | 0.35 " |
| Size / Dimension [z] | 9 mm |
| Standard Number | 55024, 60950-1, 55032 Class A |
| Type | Non-Isolated PoL Module |
| Voltage - Input (Max) [Max] | 36 V |
| Voltage - Input (Min) [Min] | 13 V |
| Voltage - Output 1 | 9 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tube | 1 | $ 7.07 | |
| 5 | $ 6.97 | |||
| 10 | $ 6.87 | |||
| 44 | $ 6.46 | |||
| 88 | $ 6.26 | |||
| 264 | $ 6.06 | |||
| 528 | $ 5.66 | |||
Description
General part information
VX7809 Series
Non-Isolated PoL Module DC DC Converter 1 Output 9V 1A 13V - 36V Input
Documents
Technical documentation and resources
No documents available
