1800774

Active

Phoenix Contact

PLUGGABLE TERMINAL BLOCKS 6 POS 5.08MM PITCH THROUGH HOLE HEADER

Search across all available documentation for this part.

Active

Phoenix Contact

PLUGGABLE TERMINAL BLOCKS 6 POS 5.08MM PITCH THROUGH HOLE HEADER

Technical Specifications

Parameters and characteristics for this part

Specification	1800774

Color	Black
Contact Mating Finish	Tin
Contact Tail Length	3.5 mm
Contact Tail Length	0.138 in
Current - IEC	10 A
Current - UL	12 A
Header Orientation	Vertical
Insulation Height	0.87 in
Insulation Height	22.1 mm
Mounting Type	Through Hole
Number of Levels	2
Number of Positions	12
Pitch [x]	0.2 in
Pitch [x]	5.08 mm
Positions Per Level	6
Termination Style	Solder
Type	Header, Male Pins, Shrouded (2 Side)
Voltage - IEC	250 V
Voltage - UL	300 V

Pluggable Terminal Blocks 6 Pos 5.08mm pitch Through Hole Header

Part	Voltage - IEC	Color	Voltage - UL	Number of Levels	Current - IEC	Termination Style	Current - UL	Contact Tail Length	Contact Tail Length	Number of Positions	Pitch [x]	Pitch [x]	Mounting Type	Type	Positions Per Level	Header Orientation	Insulation Height	Insulation Height	Contact Mating Finish
Phoenix Contact 1800774	250 V	Black	300 V	2	10 A	Solder	12 A	3.5 mm	0.138 in	12	0.2 in	5.08 mm	Through Hole	Header Male Pins Shrouded (2 Side)	6	Vertical	0.87 in	22.1 mm	Tin

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Pluggable Terminal Blocks 6 Pos 5.08mm pitch Through Hole Header

Technical documentation and resources
