T18RA50HSW
ActiveHELLERMANNTYTON
CBL TIE LOCKING BLK 18LBS 3.93"
Deep-Dive with AI
Search across all available documentation for this part.
T18RA50HSW
ActiveHELLERMANNTYTON
CBL TIE LOCKING BLK 18LBS 3.93"
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | T18RA50HSW |
|---|---|
| Bundle Diameter [diameter] | 20 mm |
| Bundle Diameter [diameter] | 0.79 in |
| Color | Black |
| Features | Heat Stabilized |
| Length - Actual | 0.328 ft |
| Length - Actual | 3.93 in |
| Length - Actual | 100 mm |
| Length - Approximate | 4 in |
| Material | Polyamide (PA66), Nylon 6/6 |
| Mounting Type | Free Hanging (In-Line) |
| Tensile Strength | 18 lbs |
| Tensile Strength | 8.16 kg |
| Width [x] | 0.098 in |
| Width [x] | 2.5 mm |
| Wire/Cable Tie Type | Standard, Locking |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 500 | $ 0.14 | |
| 1000 | $ 0.12 | |||
| 1500 | $ 0.11 | |||
| 2500 | $ 0.11 | |||
| 5000 | $ 0.10 | |||
| 12500 | $ 0.09 | |||
| 25000 | $ 0.09 | |||
| 50000 | $ 0.08 | |||
Description
General part information
T18RA Series
Standard, Locking Black 0.79" (20.00mm) 0.098" (2.50mm) 18 lbs (8.16 kg)
Documents
Technical documentation and resources
