AM20CWR-2412SZK

Active

aimtec

DC DC CONVERTER 12V 20W

Search across all available documentation for this part.

Active

aimtec

DC DC CONVERTER 12V 20W

Technical Specifications

Parameters and characteristics for this part

Part	Current - Output (Max)	Current - Output (Max)	Type	Approval Agency	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Efficiency	Voltage - Input (Max) [Max]	Features	Voltage - Isolation	Voltage - Output 1 [Max]	Voltage - Output 1 [Min]	Voltage - Output 2	Applications	Voltage - Input (Min) [Min]	Number of Outputs	Power (Watts)	Current - Output (Max) [Max]	Voltage - Output 1
aimtec AM20C-1215DZ	667 mA	667 mA	Isolated Module	CE cURus	25.4 mm	1 in	0.39 in	25.4 mm	25.4 mm	9.9 mm	-40 °C	75 ░C	Through Hole	89 %	18 V	Adjustable Output Remote On/Off	1.6 kV	15 V	-15 V	-15 V	ITE (Commercial)	9 V	2	20 W
aimtec AM20CWR-2412SZK			Isolated Module	CE	1.09 in	1.09 "	0.65 in	27.6 mm	27.6 mm	16.4 mm	-40 °C	100 °C	Through Hole	89 %	70 V	Heat Sink Remote On/Off	3000 V				ITE (Commercial)	13 V	1	20 W	1.67 A	12 V
aimtec AM20CWR-2403SZK			Isolated Module	CE	1.09 in	1.09 "	0.65 in	27.6 mm	27.6 mm	16.4 mm	-40 °C	100 °C	Through Hole	87 %	70 V	Heat Sink Remote On/Off	3000 V				ITE (Commercial)	13 V	1	20 W	4.5 A	3.3 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Isolated Module DC DC Converter 1 Output 12V 1.67A 13V - 70V Input
