1095A 0105000

Active

Belden Inc.

CABLE 36 COND 18AWG BLACK

Search across all available documentation for this part.

Active

Belden Inc.

CABLE 36 COND 18AWG BLACK

Technical Specifications

Parameters and characteristics for this part

Specification	1095A 0105000

Cable Type	Multi-Triad
Conductor Insulation	Polyamide (PA), Nylon, Poly-Vinyl Chloride (PVC)
Conductor Material	Copper, Bare
Conductor Strand [custom]	26 AWG
Conductor Strand [custom]	7
Features	Rip Cord, Drain Wire
Jacket (Insulation) Diameter [diameter]	0.94 in
Jacket (Insulation) Diameter [diameter]	23.88 mm
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC)
Jacket (Insulation) Thickness	2.108 mm
Jacket (Insulation) Thickness	0.083 in
Jacket Color	Black
Number of Conductors	36
Shield Coverage	100 %
Shield Material	Aluminum
Shield Type	Foil
Wire Gauge	18 AWG

Part	Number of Conductors	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Conductor Strand [custom]	Conductor Strand [custom]	Jacket (Insulation) Material	Shield Material	Conductor Insulation	Shield Type	Wire Gauge	Features	Conductor Material	Length [x]	Length [x]	Shield Coverage	Cable Type	Jacket Color	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Length	Length
Belden Inc. 1095A 0107500	36	0.94 in	23.88 mm	26 AWG	7	Poly-Vinyl Chloride (PVC)	Aluminum	Nylon Poly-Vinyl Chloride (PVC) Polyamide (PA)	Foil	18 AWG	Drain Wire Rip Cord	Copper Bare	7500 ft	2286 m	100 %	Multi-Triad	Black	2.108 mm	0.083 in
Belden Inc. 1095A 0102500	36	0.94 in	23.88 mm	26 AWG	7	Poly-Vinyl Chloride (PVC)	Aluminum	Nylon Poly-Vinyl Chloride (PVC) Polyamide (PA)	Foil	18 AWG	Drain Wire Rip Cord	Copper Bare			100 %	Multi-Triad	Black	2.108 mm	0.083 in	2500 ft	762 m
Belden Inc. 1095A 0105000	36	0.94 in	23.88 mm	26 AWG	7	Poly-Vinyl Chloride (PVC)	Aluminum	Nylon Poly-Vinyl Chloride (PVC) Polyamide (PA)	Foil	18 AWG	Drain Wire Rip Cord	Copper Bare			100 %	Multi-Triad	Black	2.108 mm	0.083 in

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	5000	$ 13.58

General part information

36 (12 Triad Twisted) Conductor Multi-Triad Cable Black 18 AWG Foil 5000' (1524.0m)
