BH010-12-C-0850-0840-0573-G

Active

GCT

CONN HEADER SMD 12POS 3.96MM

Search across all available documentation for this part.

Active

GCT

CONN HEADER SMD 12POS 3.96MM

Technical Specifications

Parameters and characteristics for this part

Specification	BH010-12-C-0850-0840-0573-G

Connector Type	Header
Contact Finish - Post	Tin
Contact Length - Mating	0.335 in
Contact Length - Mating	8.51 mm
Contact Material	Brass
Contact Shape	Square
Contact Type	Male Pin
Current Rating (Amps)	7.9 A
Fastening Type	Push-Pull
Features	Pick and Place
Insulation Color	Black
Insulation Height	0.125 in
Insulation Height	3.18 mm
Insulation Material	Liquid Crystal Polymer (LCP)
Material Flammability Rating	UL94 V-0
Mounting Type	Surface Mount
Number of Positions	12
Number of Positions Loaded	All
Number of Rows	1
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Pitch - Mating	0.156 in
Pitch - Mating	3.96 mm
Shrouding	Unshrouded
Termination	Solder

Part	Insulation Material	Fastening Type	Current Rating (Amps)	Shrouding	Number of Positions Loaded	Termination	Number of Rows	Contact Length - Mating	Contact Length - Mating	Mounting Type	Material Flammability Rating	Pitch - Mating	Pitch - Mating	Connector Type	Insulation Color	Operating Temperature [Min]	Operating Temperature [Max]	Contact Finish - Post	Contact Type	Insulation Height	Insulation Height	Contact Material	Number of Positions	Contact Shape	Features
GCT BH010-12-C-0850-0840-0573-G	Liquid Crystal Polymer (LCP)	Push-Pull	7.9 A	Unshrouded	All	Solder	1	0.335 in	8.51 mm	Surface Mount	UL94 V-0	0.156 in	3.96 mm	Header	Black	-40 °C	105 ░C	Tin	Male Pin	0.125 in	3.18 mm	Brass	12	Square	Pick and Place

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Connector Header Surface Mount 12 position 0.156" (3.96mm)
