CI3303S0010

Active

Cvilux USA

CONN RCPT HSG 3POS 2.54MM

Search across all available documentation for this part.

DocumentsCI3301SE

Active

Cvilux USA

CONN RCPT HSG 3POS 2.54MM

DocumentsCI3301SE

Technical Specifications

Parameters and characteristics for this part

Specification	CI3303S0010

Color	Black
Connector Type	Receptacle
Contact Termination	Crimp
Contact Type	Female Socket
Fastening Type	Latch Lock
Insulation Material	Polybutylene Terephthalate (PBT)
Mounting Type	Free Hanging (In-Line)
Note	Contacts Not Included
Number of Rows	1
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Pitch [x]	2.54 mm
Pitch [x]	0.1 in

Part	Insulation Material	Mounting Type	Pitch [x]	Pitch [x]	Contact Termination	Fastening Type	Color	Contact Type	Connector Type	Operating Temperature [Min]	Operating Temperature [Max]	Note	Number of Rows
Cvilux USA CI3303S0010	Polybutylene Terephthalate (PBT)	Free Hanging (In-Line)	2.54 mm	0.1 in	Crimp	Latch Lock	Black	Female Socket	Receptacle	-40 °C	105 ░C	Contacts Not Included	1

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

3 Rectangular Connectors - Housings Receptacle Black 0.100" (2.54mm)
