RFAA4240J240J

Active

BULGIN LIMITED

RF / COAXIAL ADAPTER, 2.4MM COAXIAL, JACK, 2.4MM COAXIAL, JACK, STRAIGHT PANEL ADAPTER, 50 OHM

Search across all available documentation for this part.

Active

BULGIN LIMITED

RF / COAXIAL ADAPTER, 2.4MM COAXIAL, JACK, 2.4MM COAXIAL, JACK, STRAIGHT PANEL ADAPTER, 50 OHM

Technical Specifications

Parameters and characteristics for this part

Specification	RFAA4240J240J

Adapter Series [Max]	2.4 mm
Adapter Series [Min]	2.4 mm
Adapter Type	Jack to Jack
Body Material	Stainless Steel
Center Contact Material	Beryllium Copper
Center Gender	Female to Female
Conversion Type	Same Series
Convert From (Adapter End)	2.4 mm
Convert To (Adapter End)	2.4 mm
Dielectric Material	Polyetherimide (PEI), Polytetrafluoroethylene (PTFE)
Frequency - Max [Max]	50 GHz
Impedance	50 Ohms
Mating Cycles	500
Mounting Feature	Flange
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Style	Straight

Part	Impedance	Adapter Series [Max]	Adapter Series [Min]	Operating Temperature [Max]	Operating Temperature [Min]	Adapter Type	Mating Cycles	Center Gender	Mounting Feature	Dielectric Material	Convert From (Adapter End)	Frequency - Max [Max]	Body Material	Conversion Type	Convert To (Adapter End)	Style	Center Contact Material
BULGIN LIMITED RFAA4240J240J	50 Ohms	2.4 mm	2.4 mm	85 °C	-40 °C	Jack to Jack	500	Female to Female	Flange	Polyetherimide (PEI) Polytetrafluoroethylene (PTFE)	2.4 mm	50 GHz	Stainless Steel	Same Series	2.4 mm	Straight	Beryllium Copper

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	50	$ 200.09
Newark	Each	1	$ 331.46

General part information

Adapter Coaxial Connector 2.4mm (APC-2.4, OS-50) Jack, Female Socket To 2.4mm (APC-2.4, OS-50) Jack, Female Socket 50 Ohms
