FH67-10S-0.5SV

Active

Hirose Electric USA, Inc.

CONN FFC VERT 10POS 0.5MM SMD

Search across all available documentation for this part.

Active

Hirose Electric USA, Inc.

CONN FFC VERT 10POS 0.5MM SMD

Technical Specifications

Parameters and characteristics for this part

Specification	FH67-10S-0.5SV

Actuator Color	Black
Actuator Material	Liquid Crystal Polymer (LCP)
Cable End Type	Notched
Connector/Contact Type	Contacts, Vertical - 1 Sided
Contact Finish	Gold
Contact Material	Copper Alloy
Current Rating (Amps)	0.5 A
Features	Solder Retention
FFC, FCB Thickness	0.33 mm
Flat Flex Type	FPC, FFC
Height Above Board	0.205 in
Height Above Board	5.2 mm
Housing Color	Gray
Housing Material	Liquid Crystal Polymer (LCP)
Locking Feature	Rotary Lock
Material Flammability Rating	UL94 V-0
Mating Cycles	10
Mounting Type	Surface Mount
Number of Positions	10
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 °C
Pitch [x]	0.5 mm
Pitch [x]	0.02 in
Termination	Solder
Voltage Rating	50 V

Part	Connector/Contact Type	Voltage Rating	Contact Material	Housing Material	Material Flammability Rating	Cable End Type	Actuator Color	Height Above Board	Height Above Board	Features	Mounting Type	Termination	Housing Color	Pitch [x]	Pitch [x]	Mating Cycles	Locking Feature	Current Rating (Amps)	Flat Flex Type	Contact Finish	Actuator Material	Operating Temperature [Min]	Operating Temperature [Max]	FFC, FCB Thickness	Number of Positions
Hirose Electric USA, Inc. FH67-40S-0.5SV	Contacts Vertical - 1 Sided	50 V	Copper Alloy	Liquid Crystal Polymer (LCP)	UL94 V-0	Notched	Black	0.205 in	5.2 mm	Solder Retention	Surface Mount	Solder	Gray	0.5 mm	0.02 in	10	Rotary Lock	0.5 A	FFC FPC	Gold	Liquid Crystal Polymer (LCP)	-55 °C	125 °C	0.33 mm	40
Hirose Electric USA, Inc. FH67-10S-0.5SV	Contacts Vertical - 1 Sided	50 V	Copper Alloy	Liquid Crystal Polymer (LCP)	UL94 V-0	Notched	Black	0.205 in	5.2 mm	Solder Retention	Surface Mount	Solder	Gray	0.5 mm	0.02 in	10	Rotary Lock	0.5 A	FFC FPC	Gold	Liquid Crystal Polymer (LCP)	-55 °C	125 °C	0.33 mm	10
Hirose Electric USA, Inc. FH67-20S-0.5SV	Contacts Vertical - 1 Sided	50 V	Copper Alloy	Liquid Crystal Polymer (LCP)	UL94 V-0	Notched	Black	0.205 in	5.2 mm	Solder Retention	Surface Mount	Solder	Gray	0.5 mm	0.02 in	10	Rotary Lock	0.5 A	FFC FPC	Gold	Liquid Crystal Polymer (LCP)	-55 °C	125 °C	0.33 mm	20

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

10 Position FFC, FPC Connector Contacts, Vertical - 1 Sided 0.020" (0.50mm) Surface Mount
