0298100.ZXB
ActiveLittelfuse/Commercial Vehicle Products
FUSE - MEGA 32V AG PLATED 100A/ BULK ROHS COMPLIANT: YES
Deep-Dive with AI
Search across all available documentation for this part.
0298100.ZXB
ActiveLittelfuse/Commercial Vehicle Products
FUSE - MEGA 32V AG PLATED 100A/ BULK ROHS COMPLIANT: YES
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 0298100.ZXB |
|---|---|
| Approval Agency | cULus |
| Breaking Capacity @ Rated Voltage | 2 kA |
| Color | Yellow |
| Current Rating (Amps) | 100 A |
| DC Cold Resistance | 0.000562 Ohms |
| Fuse Type | Automotive |
| Melting I²t | 31100 |
| Mounting Type | Bolt Mount |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | Auto Link |
| Response Time | Slow Blow |
| Size / Dimension [x] | 29.2 mm |
| Size / Dimension [x] | 1.149 in |
| Size / Dimension [y] | 19.05 mm |
| Size / Dimension [y] | 0.75 in |
| Size / Dimension [z] | 0.39 in |
| Size / Dimension [z] | 9.9 mm |
| Voltage Rating - DC | 32 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
0298100.ZXB Series
This 100 A MEGA® SLO-BLO® automotive fuse employs diffusion pill technology to provide time-delay circuit protection. Use it to ensure continuous current flow along heavy gauge wire harnesses, particularly those for batteries and alternators.
