Technical Specifications
Parameters and characteristics for this part
| Specification | S8081-46R |
|---|---|
| Accepts Pin Diameter [diameter] | 0.7 mm |
| Accepts Pin Diameter [diameter] | 0.028 in |
| Contact Finish | Tin |
| Contact Material | Stainless Steel |
| Length - Overall [x] | 2.79 mm |
| Length - Overall [x] | 0.11 " |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Tail Type | No Tail |
| Termination | Solder |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 0.22 | |
| 10 | $ 0.18 | |||
| 25 | $ 0.16 | |||
| 50 | $ 0.15 | |||
| 100 | $ 0.14 | |||
| 250 | $ 0.13 | |||
| 500 | $ 0.12 | |||
| 1000 | $ 0.10 | |||
| 2500 | $ 0.09 | |||
| Digi-Reel® | 1 | $ 0.22 | ||
| 10 | $ 0.18 | |||
| 25 | $ 0.16 | |||
| 50 | $ 0.15 | |||
| 100 | $ 0.14 | |||
| 250 | $ 0.13 | |||
| 500 | $ 0.12 | |||
| 1000 | $ 0.10 | |||
| 2500 | $ 0.09 | |||
| Tape & Reel (TR) | 10000 | $ 0.07 | ||
| Newark | Each | 1 | $ 0.17 | |
| 10 | $ 0.14 | |||
| 100 | $ 0.11 | |||
| 500 | $ 0.10 | |||
| 1000 | $ 0.09 | |||
| 2500 | $ 0.08 | |||
Description
General part information
S8081 Series
Pin Receptacle Connector 0.028" (0.70mm) No Tail Solder
