AM4T-1224SZ

Active

aimtec

DC DC CONVERTER 24V 4W

Search across all available documentation for this part.

Active

aimtec

DC DC CONVERTER 24V 4W

Technical Specifications

Parameters and characteristics for this part

Part	Efficiency	Voltage - Isolation	Approval Agency	Number of Outputs	Power (Watts)	Applications	Type	Voltage - Input (Min) [Min]	Voltage - Input (Max) [Max]	Mounting Type	Current - Output (Max) [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Output 1	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [y]	Package / Case	Voltage - Output 1 [Max]	Voltage - Output 1 [Min]	Voltage - Output 2	Current - Output (Max)	Current - Output (Max)
aimtec AM4T-1224SZ	80 %	3.5 kV	CE UL	1	4 W	ITE (Commercial)	Isolated Module	9 V	18 V	Through Hole	166 mA	85 °C	-40 °C	24 V	31.8 mm	0.4 "	1.25 "	10.2 mm	0.8 in	20.3 mm	24-DIP Module
aimtec AM4T-2415DZ	80 %	3.5 kV	CE UL	2	4 W	ITE (Commercial)	Isolated Module	18 V	36 V	Through Hole		85 °C	-40 °C		31.8 mm	0.4 "	1.25 "	10.2 mm	0.8 in	20.3 mm	24-DIP Module 8 Leads	15 V	-15 V	-15 V	133 mA	133 mA

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Isolated Module DC DC Converter 1 Output 24V 166mA 9V - 18V Input
