PS2-42SC
LTBHirose Electric USA, Inc.
330A PLUG-IN CONNECTORS FOR STORAGE BATTERY APPLICATIONS
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
PS2-42SC
LTBHirose Electric USA, Inc.
330A PLUG-IN CONNECTORS FOR STORAGE BATTERY APPLICATIONS
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | PS2-42SC |
|---|---|
| Color | Black |
| Connector Type | Receptacle |
| Contact Termination | Crimp |
| Contact Type | Female Socket |
| Fastening Type | Latch Lock |
| Insulation Material | Synthetic Resin |
| Mounting Type | Free Hanging (In-Line) |
| Note | Contacts Not Included |
| Number of Positions | 42 |
| Number of Rows | 6 |
| Operating Temperature [Max] | 105 ░C |
| Operating Temperature [Min] | -40 °C |
| Pitch [x] | 4.6 mm |
| Pitch [x] | 0.181 in |
| Row Spacing | 6.2 mm |
| Row Spacing | 0.244 in |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
PS2-42 Series
42 Rectangular Connectors - Housings Receptacle Black 0.181" (4.60mm)
