CPCI-A-3U-300C

Obsolete

Murata Power Solutions Inc.

AC/DC CNVRTR 5V 3.3V +/-12V 300W

Search across all available documentation for this part.

Obsolete

Murata Power Solutions Inc.

AC/DC CNVRTR 5V 3.3V +/-12V 300W

Technical Specifications

Parameters and characteristics for this part

Specification	CPCI-A-3U-300C

Applications	ITE (Commercial)
Approval Agency	CE
Current - Output 1	30 A
Current - Output 2	40 A
Current - Output 3	5 A
Current - Output 4	500 mA
Efficiency	81 %
Features	PFC, Hot Swappable, Universal Input
Mounting Type	Compact PCI®
Number of Outputs	4
Operating Temperature [Max]	50 °C
Operating Temperature [Min]	-5 °C
Power (Watts)	300 W
Size / Dimension [x]	169.6 mm
Size / Dimension [x]	6.68 "
Size / Dimension [y]	1.59 "
Size / Dimension [y]	40.3 mm
Size / Dimension [z]	128.6 mm
Size / Dimension [z]	5.06 "
Type	Enclosed
Voltage - Input [Max]	264 VAC
Voltage - Input [Min]	90 VAC
Voltage - Isolation	3000 V
Voltage - Output 1	5 V
Voltage - Output 2	3.3 V
Voltage - Output 3	12 V

Part	Efficiency	Voltage - Output 3	Number of Outputs	Approval Agency	Current - Output 3	Applications	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Input [Min]	Voltage - Input [Max]	Current - Output 4	Voltage - Output 1	Mounting Type	Type	Voltage - Isolation	Features	Current - Output 1	Voltage - Output 2	Current - Output 2	Power (Watts)	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]
Murata Power Solutions Inc. CPCI-A-3U-300C	81 %	12 V	4	CE	5 A	ITE (Commercial)	50 °C	-5 °C	90 VAC	264 VAC	500 mA	5 V	Compact PCI®	Enclosed	3000 V	Hot Swappable PFC Universal Input	30 A	3.3 V	40 A	300 W	169.6 mm	128.6 mm	1.59 "	5.06 "	40.3 mm	6.68 "

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Enclosed AC DC Converters 4 Output 5V 3.3V 12V -12V 90 ~ 264 VAC Input
