D2864-42

Obsolete

Harwin Inc.

CONN IC DIP SOCKET 64POS GOLD

Search across all available documentation for this part.

Obsolete

Harwin Inc.

CONN IC DIP SOCKET 64POS GOLD

Technical Specifications

Parameters and characteristics for this part

Specification	D2864-42

Contact Finish - Mating	Gold
Contact Finish - Post	Tin
Contact Finish Thickness - Mating	Flash
Contact Finish Thickness - Post	196.9 µin
Contact Finish Thickness - Post	5 µm
Contact Material - Mating	Beryllium Copper
Contact Material - Post [custom]	Brass
Contact Resistance	10 mOhm
Current Rating (Amps)	1 A
Features	Open Frame
Housing Material	Plastic
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole
Number of Positions or Pins (Grid)	64
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 °C
Pitch - Mating	0.1 in
Pitch - Mating	2.54 mm
Pitch - Post	2.54 mm
Pitch - Post	0.1 in
Termination	Solder
Termination Post Length	3.2 mm
Termination Post Length	0.126 in
Type	DIP
Type	0.6 in
Type	15.24 mm

Part	Number of Positions or Pins (Grid)	Pitch - Mating	Pitch - Mating	Contact Finish Thickness - Mating	Contact Finish - Mating	Operating Temperature [Min]	Operating Temperature [Max]	Material Flammability Rating	Contact Resistance	Pitch - Post	Pitch - Post	Housing Material	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Contact Material - Post [custom]	Mounting Type	Features	Contact Material - Mating	Termination	Type	Type	Type	Contact Finish - Post	Termination Post Length	Termination Post Length	Current Rating (Amps)
Harwin Inc. D2864-42	64	0.1 in	2.54 mm	Flash	Gold	-55 °C	125 °C	UL94 V-0	10 mOhm	2.54 mm	0.1 in	Plastic	196.9 µin	5 µm	Brass	Through Hole	Open Frame	Beryllium Copper	Solder	DIP	0.6 in	15.24 mm	Tin	3.2 mm	0.126 in	1 A

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

64 (2 x 32) Pos DIP, 0.6" (15.24mm) Row Spacing Socket Gold Through Hole
