1312A 0101000

Active

Belden Inc.

4 #12 PE FRPVC

Search across all available documentation for this part.

Active

Belden Inc.

4 #12 PE FRPVC

Technical Specifications

Parameters and characteristics for this part

Specification	1312A 0101000

Cable Type	Speaker
Conductor Insulation	Polyethylene (PE)
Conductor Material	Copper, Bare
Conductor Strand [custom]	34 AWG
Conductor Strand [custom]	168
Features	Direct Burial
Jacket (Insulation) Diameter [diameter]	0.423 in
Jacket (Insulation) Diameter [diameter]	10.74 mm
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC)
Jacket Color	Black
Length	1000 ft
Length	304.8 m
Number of Conductors	4
Usage	Home, Audio-Video
Voltage	300 V
Wire Gauge	12 AWG

Part	Conductor Strand [custom]	Conductor Strand [custom]	Length	Length	Jacket Color	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Features	Cable Type	Conductor Material	Usage	Wire Gauge	Voltage	Number of Conductors	Conductor Insulation	Jacket (Insulation) Material
Belden Inc. 1312A 0101000	34 AWG	168	1000 ft	304.8 m	Black	0.423 in	10.74 mm	Direct Burial	Speaker	Copper Bare	Audio-Video Home	12 AWG	300 V	4	Polyethylene (PE)	Poly-Vinyl Chloride (PVC)

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	1000	$ 3.05

General part information

4 Conductor Speaker Cable Black 12 AWG 1000.0' (304.8m)

Technical documentation and resources
