0272001.V

Active

Littelfuse/Commercial Vehicle Products

FUSE, PCB LEADED, 1 A, 125 V, MICRO 272 SERIES, 125 V, VERY FAST ACTING, RADIAL LEADED

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet Circuit Protection Technology Application Matrix +1

0272001.V

Active

Littelfuse/Commercial Vehicle Products

FUSE, PCB LEADED, 1 A, 125 V, MICRO 272 SERIES, 125 V, VERY FAST ACTING, RADIAL LEADED

Deep-Dive with AI

DocumentsDatasheet Circuit Protection Technology Application Matrix +1

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	0272001.V

Approval Agency	CSA, UL, QPL
Current Rating (Amps)	1 A
DC Cold Resistance	0.088 Ohms
Fuse Type	Board Mount
Melting I²t	0.0648
Mounting Type	Through Hole
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 °C
Package / Case	Vertical, Radial, Can
Response Time	Fast Blow
Size / Dimension [diameter]	5.97 mm
Size / Dimension [diameter]	0.235 "
Size / Dimension [z]	7.3 mm
Size / Dimension [z]	0.287 "
Voltage Rating - AC	125 V
Voltage Rating - DC	125 VDC

0272001 Series

3FUSE 125V V/FA MICRO FUSE 1A

Part	Voltage Rating - DC	Melting I²t	Package / Case	Mounting Type	DC Cold Resistance	Size / Dimension [diameter]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [diameter]	Fuse Type	Approval Agency	Response Time	Current Rating (Amps)	Voltage Rating - AC	Operating Temperature [Min]	Operating Temperature [Max]
Littelfuse/Commercial Vehicle Products 0272001.V	125 VDC	0.0648	Can Radial Vertical	Through Hole	0.088 Ohms	5.97 mm	7.3 mm	0.287 "	0.235 "	Board Mount	CSA QPL UL	Fast Blow	1 A	125 V	-55 °C	125 °C

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	5	$ 12.75
Newark	Each	1	$ 12.15
		10	$ 11.54
		25	$ 9.99
		50	$ 9.28
		100	$ 8.17
		250	$ 7.79
		500	$ 7.23

Description

General part information

0272001 Series

Developed originally for the U.S. Space Program, MICRO™ fuse provides reliability in a compact design. The MICRO™ fuse is available in plug–in or radial lead styles and a complete range of ampere ratings from 1/500 to 5A to suit a wide variety of design needs.
