ZMID52013AE1T

Active

Renesas Electronics Corporation

SENSOR ROTARY 360DEG SMD

Search across all available documentation for this part.

Active

Renesas Electronics Corporation

SENSOR ROTARY 360DEG SMD

Technical Specifications

Parameters and characteristics for this part

Specification	ZMID52013AE1T

Actuator Type	Inductive Target
For Measuring	Rotary Position, Linear
Mounting Type	Surface Mount
Output	Analog Voltage
Output Signal	Clockwise Increase
Package / Case	14-TSSOP
Package / Case [custom]	0.173 "
Package / Case [custom]	4.4 mm
Rotation Angle - Electrical, Mechanical [Max]	360 °
Rotation Angle - Electrical, Mechanical [Min]	0 °
Supplier Device Package	14-TSSOP
Technology	Inductive
Termination Style	Gull Wing
Voltage - Supply [Max]	5.5 V
Voltage - Supply [Min]	4.5 V

Part	Voltage - Supply [Min]	Voltage - Supply [Max]	Mounting Type	Technology	Rotation Angle - Electrical, Mechanical [Max]	Rotation Angle - Electrical, Mechanical [Min]	Supplier Device Package	Termination Style	Actuator Type	For Measuring	Output Signal	Output	Package / Case [custom]	Package / Case [custom]	Package / Case
Renesas Electronics Corporation ZMID52013AE1T	4.5 V	5.5 V	Surface Mount	Inductive	360 °	0 °	14-TSSOP	Gull Wing	Inductive Target	Linear Rotary Position	Clockwise Increase	Analog Voltage	0.173 "	4.4 mm	14-TSSOP

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Inductive Sensor Linear, Rotary Position Inductive Target Gull Wing
