ESP32-D2WD
ObsoleteEspressif Systems
IC RF TXRX+MCU BLE 48QFN
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
ESP32-D2WD
ObsoleteEspressif Systems
IC RF TXRX+MCU BLE 48QFN
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | ESP32-D2WD |
|---|---|
| Current - Receiving | 100 mA |
| Current - Transmitting | 240 mA |
| Data Rate (Max) | 150 Mbps |
| Frequency | 2.4 GHz |
| GPIO | 34 |
| Memory Size | 2 MB, 448 kB, 520 kB |
| Modulation | DSSS, OFDM, CCK |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 48-VFQFN Exposed Pad |
| Power - Output | 20 dBm |
| Protocol | 802.11b/g/n, Bluetooth 4.2 |
| RF Family/Standard | WiFi, Bluetooth |
| Sensitivity | -98 dBm |
| Serial Interfaces | SPI, I2C, I2S, UART |
| Supplier Device Package | 48-QFN (5x5) |
| Type | TxRx + MCU |
| Voltage - Supply [Max] | 3.6 V |
| Voltage - Supply [Min] | 2.3 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
ESP32-D2 Series
IC RF TxRx + MCU Bluetooth, WiFi 802.11b/g/n, Bluetooth 4.2 2.4GHz 48-VFQFN Exposed Pad
