TM1RBJ - TM1RBJ

TM1RBJ

Active
AMPHENOL AUDIO

PHONE AUDIO CONNECTOR, PLUG, 2, CABLE MOUNT, THERMOPLASTIC BODY, NICKEL PLATED CONTACTS ROHS COMPLIANT: YES

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheetEnhanced Product Overview EN+1
TM1RBJ - TM1RBJ

TM1RBJ

Active
AMPHENOL AUDIO

PHONE AUDIO CONNECTOR, PLUG, 2, CABLE MOUNT, THERMOPLASTIC BODY, NICKEL PLATED CONTACTS ROHS COMPLIANT: YES

Deep-Dive with AI

DocumentsDatasheetEnhanced Product Overview EN+1

Technical Specifications

Parameters and characteristics for this part

SpecificationTM1RBJ
Body ColorSilver, Black
Connector TypePhone Plug
Contact MaterialBrass
Contact Material - Plating [custom]Nickel
Current Rating (Amps)10 A
GenderMale
Housing MaterialZinc Alloy
Internal Switch(s)False
Mating Length/Depth1.19 in
Mating Length/Depth30.3 mm
Mounting TypeFree Hanging (In-Line), Right Angle
Number of Positions/Contacts [custom]3
Number of Positions/Contacts [custom]3
Operating Temperature [Max]75 ░C
Operating Temperature [Min]-25 °C
ShieldingUnshielded
Signal LinesMono
TerminationSolder Eyelet(s)

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

DistributorPackageQuantity$
DigikeyBulk 300$ 11.93
NewarkEach 1$ 17.13
5$ 16.38
10$ 15.69
25$ 14.66
50$ 13.42
100$ 12.59
250$ 12.32

Description

General part information

TM1 Series

6.35mm (0.250", 1/4") - Headphone Phone Plug Mono Connector Solder Eyelet(s)
