39H102C

Active

Murata Power Solutions Inc.

POWER INDUCTOR (SMD), 1 ΜH, 17.5 A, UNSHIELDED, 20 A, 3900 SERIES

Search across all available documentation for this part.

Active

Murata Power Solutions Inc.

POWER INDUCTOR (SMD), 1 ΜH, 17.5 A, UNSHIELDED, 20 A, 3900 SERIES

Technical Specifications

Parameters and characteristics for this part

Part	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Type	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Mounting Type	Shielding	Inductance	DC Resistance (DCR) [Max]	Current Rating (Amps)	Package / Case	Inductance Frequency - Test	Tolerance	Operating Temperature [Max]	Operating Temperature [Min]	Current - Saturation (Isat)
Murata Power Solutions Inc. 39H182C	0.508 in	12.9 mm	0.508 in	12.9 mm	Wirewound	5.8 mm	0.228 "	Surface Mount	Unshielded	1.8 µH	3.9 mOhm	13.5 A	Nonstandard	100 kHz	20 %	125 °C	-40 °C	15.3 A
Murata Power Solutions Inc. 39H562C	0.508 in	12.9 mm	0.508 in	12.9 mm	Wirewound	5.8 mm	0.228 "	Surface Mount	Unshielded	5.6 µH	11.4 mOhm	8.2 A	Nonstandard	100 kHz	20 %	125 °C	-40 °C	8.8 A
Murata Power Solutions Inc. 39H471C	0.508 in	12.9 mm	0.508 in	12.9 mm	Wirewound	5.8 mm	0.228 "	Surface Mount	Unshielded	470 nH	1.9 mOhm	19.5 A	Nonstandard	100 kHz	30 %	125 °C	-40 °C	28.8 A
Murata Power Solutions Inc. 39H102C	0.508 in	12.9 mm	0.508 in	12.9 mm	Wirewound	5.8 mm	0.228 "	Surface Mount	Unshielded	1 µH	2.5 mOhm	17.5 A	Nonstandard	100 kHz	20 %	125 °C	-40 °C	20 A
Murata Power Solutions Inc. 39H402C	0.508 in	12.9 mm	0.508 in	12.9 mm	Wirewound	5.8 mm	0.228 "	Surface Mount	Unshielded	4 µH	8 mOhm	9.7 A	Nonstandard	100 kHz	20 %	125 °C	-40 °C	10.3 A
Murata Power Solutions Inc. 39H282C	0.508 in	12.9 mm	0.508 in	12.9 mm	Wirewound	5.8 mm	0.228 "	Surface Mount	Unshielded	2.8 µH	5.4 mOhm	11 A	Nonstandard	100 kHz	20 %	125 °C	-40 °C	12.3 A

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tape & Reel (TR)	550	$ 1.11
Newark	Each (Supplied on Cut Tape)	1	$ 1.41

General part information

1 µH Unshielded Wirewound Inductor 17.5 A 2.5mOhm Max Nonstandard
