FAD1-09225DBLW11

Active

Qualtek

FAN AXIAL 92.5X25MM 24VDC WIRE

Search across all available documentation for this part.

Active

Qualtek

FAN AXIAL 92.5X25MM 24VDC WIRE

Technical Specifications

Parameters and characteristics for this part

Part	RPM	Material - Blade	Operating Temperature [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Operating Temperature [Min]	Voltage Range [Max]	Voltage Range [Min]	Material - Frame	Current Rating (Amps)	Static Pressure	Static Pressure	Size / Dimension [x]	Size / Dimension [z]	Noise	Air Flow	Air Flow	Weight	Weight	Bearing Type	Power (Watts)	Termination	Width [y]	Fan Type	Approval Agency	Voltage - Rated
Qualtek FAD1-09225CBLW11	2100 RPM	Plastic	70 °C	70 °C	-10 °C	-10 °C	13.2 VDC	10.8 VDC	Plastic	100 mA	0.081 in H2O	20.1 Pa	92.5 mm	92.5 mm	29.2 dB(A)	40.7 CFM	1.14 m³/min	92.08 g	0.203 lb	Ball	1.2 W	2 Wire Leads	25 mm	Tubeaxial	CE cURus TUV	12 VDC
Qualtek FAD1-09225DBLW11	2100 RPM	Plastic	70 °C	70 °C	-10 °C	-10 °C	26.4 VDC	21.6 VDC	Plastic	50 mA	0.081 in H2O	20.1 Pa	92.5 mm	92.5 mm	29.2 dB(A)	40.7 CFM	1.14 m³/min	92.08 g	0.203 lb	Ball	1.2 W	2 Wire Leads	25 mm	Tubeaxial	CE cURus TUV	24 VDC
Qualtek FAD1-09225DBJW12	3300 RPM	Plastic	70 °C	70 °C	-10 °C	-10 °C	26.4 VDC	21.6 VDC	Plastic		0.187 in H2O	46.6 Pa	92.5 mm	92.5 mm	42.2 dB(A)	61.9 CFM	1.73 mł/min	92.08 g	0.203 lb	Ball	3.64 W	2 Wire Leads	25 mm	Tubeaxial	CE cURus TUV	24 VDC

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Fan Tubeaxial 24VDC Square - 92.5mm L x 92.5mm H Ball 40.7 CFM (1.14m³/min) 2 Wire Leads
