120-A-111/03
ActiveWECO Electrical Connectors Inc.
PLUG PLUG-IN SCREW; 3POS 5MM PIT
Deep-Dive with AI
Search across all available documentation for this part.
120-A-111/03
ActiveWECO Electrical Connectors Inc.
PLUG PLUG-IN SCREW; 3POS 5MM PIT
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 120-A-111/03 |
|---|---|
| Color | Gray |
| Contact Material | Copper Alloy |
| Contact Mating Finish | Tin |
| Housing Material | Polyamide (PA), Nylon |
| Insulation Height | 0.59 in |
| Insulation Height | 14.99 mm |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Free Hanging (In-Line) |
| Number of Levels | 1 |
| Operating Temperature [Max] | 105 ░C |
| Operating Temperature [Min] | -40 °C |
| Pitch [x] | 5 mm |
| Pitch [x] | 0.197 in |
| Positions Per Level | 3 |
| Screw Size | M3 |
| Termination Style | Screw - Rising Cage Clamp |
| Torque - Screw | 0.51 Nm |
| Torque - Screw | 4.5 Lb-In |
| Type | Plug, Female Sockets |
| Voltage - UL | 300 V |
| Wire Gauge or Range - AWG [Max] | 26 AWG |
| Wire Gauge or Range - AWG [Min] | 12 AWG |
| Wire Gauge or Range - mm² | 2.5 mm² |
| Wire Strip Length | 7 mm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 2.36 | |
| 10 | $ 1.43 | |||
| 25 | $ 1.25 | |||
| 50 | $ 1.15 | |||
| 100 | $ 1.08 | |||
| 250 | $ 1.01 | |||
| 500 | $ 0.97 | |||
| 1000 | $ 0.94 | |||
| 5000 | $ 0.90 | |||
Description
General part information
120-A-11 Series
3 Position Terminal Block Plug, Female Sockets 0.197" (5.00mm) 180° Free Hanging (In-Line)
