LC1G2254LSEA

Active

SQUARE D BY SCHNEIDER ELECTRIC

CONTACTOR: 4-POLE; NO X4; AUXILIARY CONTACTS: NO + NC; 225A; 1KV

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsTechnical Data Sheet EN

LC1G2254LSEA

Active

SQUARE D BY SCHNEIDER ELECTRIC

CONTACTOR: 4-POLE; NO X4; AUXILIARY CONTACTS: NO + NC; 225A; 1KV

Deep-Dive with AI

DocumentsTechnical Data Sheet EN

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	LC1G2254LSEA

Coil Voltage [Max]	500 VAC/DC
Coil Voltage [Min]	200 VAC/DC
Contact Form	4PST-NO (4 Form A)
Contact Rating (Current)	330 A
Features	Auxiliary Contacts
Mounting Type	Chassis Mount
Operate Time	70 ms
Operating Temperature [Max]	60 °C
Operating Temperature [Min]	-25 °C
Release Time	50 ms
Switching Voltage	460 VDC, 1000 VAC
Termination Style	Spring Terminal

tesys-g Series

Part	Mounting Type	Termination Style	Features	Operate Time	Operating Temperature [Min]	Operating Temperature [Max]	Release Time	Switching Voltage	Contact Form	Contact Rating (Current)	Coil Voltage [Min]	Coil Voltage [Max]
SQUARE D BY SCHNEIDER ELECTRIC LC1G500LSEA	Chassis Mount	Box Lug	Auxiliary Contacts	70 ms	-25 °C	60 °C	50 ms	460 VDC 1000 VAC	3PST-NO (3 Form A)	500 A	200 VAC/DC	500 VAC/DC
SQUARE D BY SCHNEIDER ELECTRIC LC1G1504LSEA	Chassis Mount	Spring Terminal	Auxiliary Contacts	70 ms	-25 °C	60 °C	50 ms	460 VDC 1000 VAC	4PST-NO (4 Form A)	275 A	200 VAC/DC	500 VAC/DC
SQUARE D BY SCHNEIDER ELECTRIC LC1G2654EHEN	Chassis Mount	Box Lug	Auxiliary Contacts	70 ms	-25 °C	60 °C	50 ms	460 VDC 1000 VAC	4PST-NO (4 Form A)	385 A	48 VAC/DC	130 VAC/DC
SQUARE D BY SCHNEIDER ELECTRIC LC1G1854KUEN	Chassis Mount	Box Lug	Auxiliary Contacts	70 ms	-25 °C	60 °C	50 ms	460 VDC 1000 VAC	4PST-NO (4 Form A)	305 A	100 VAC/DC	250 VAC/DC
SQUARE D BY SCHNEIDER ELECTRIC LC1G225EHEN	Chassis Mount	Spring Terminal	Auxiliary Contacts	70 ms	-40 °C	70 °C	50 ms	460 VDC 1000 VAC	3PST-NO (3 Form A)	25 A	48 VAC/DC	130 VAC/DC
SQUARE D BY SCHNEIDER ELECTRIC LC1G2254EHEN	Chassis Mount	Spring Terminal	Auxiliary Contacts	70 ms	-40 °C	70 °C	50 ms	460 VDC 1000 VAC	4PST-NO (4 Form A)	330 A	48 VAC/DC	130 VAC/DC
SQUARE D BY SCHNEIDER ELECTRIC LC1G4004EHEN	Chassis Mount	Spring Terminal	Auxiliary Contacts	70 ms	-25 °C	60 °C	50 ms	460 VDC 1000 VAC	4PST-NO (4 Form A)	550 A	48 VAC/DC	130 VAC/DC
SQUARE D BY SCHNEIDER ELECTRIC LC1G330EHEN	Chassis Mount	Box Lug	Auxiliary Contacts	70 ms	-40 °C	70 °C	50 ms	460 VDC 1000 VAC	3PST-NO (3 Form A)	330 A	48 VAC/DC	130 VAC/DC
SQUARE D BY SCHNEIDER ELECTRIC LC1G2254LSEA	Chassis Mount	Spring Terminal	Auxiliary Contacts	70 ms	-25 °C	60 °C	50 ms	460 VDC 1000 VAC	4PST-NO (4 Form A)	330 A	200 VAC/DC	500 VAC/DC
SQUARE D BY SCHNEIDER ELECTRIC LC1G1854LSEA	Chassis Mount	Box Lug	Auxiliary Contacts	70 ms	-25 °C	60 °C	50 ms	460 VDC 1000 VAC	4PST-NO (4 Form A)	305 A	200 VAC/DC	500 VAC/DC

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 1739.26
Newark	Each	5	$ 2089.33
		10	$ 2045.50
		25	$ 1928.62
TME	N/A	1	$ 23.42
		5	$ 21.96
		10	$ 20.50

Description

General part information

tesys-g Series

CONTACTOR: 4-POLE; NO X4; AUXILIARY CONTACTS: NO + NC; 225A; 1KV

Documents

Technical documentation and resources

Technical Data Sheet EN

Datasheet
