RJFTV6MBZ

Active

Amphenol Socapex

CONN MOD PLUG HSG RJ45

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

RJFTV6MBZ

Active

Amphenol Socapex

CONN MOD PLUG HSG RJ45

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	RJFTV6MBZ

Connector Type	Housing for Prewired RJ45 Cordset
Fastening Type	Bayonet Lock
Features	Toolless, Shock Resistant, Vibration Resistant
Ingress Protection	IP67 - Dust Tight, Waterproof
Mating Cycles	500
Mounting Type	Free Hanging (In-Line)
Note	Plug Not Provided
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Shielding	Unshielded

RJFTV6 Series

Part	Operating Temperature [Max]	Operating Temperature [Min]	Connector Type	Color	Mating Cycles	Mounting Type	Note	Shielding	Ingress Protection	Features	Convert To (Adapter End)	Type	Shell Material, Finish	Ratings	Convert From (Adapter End)	Fastening Type
Amphenol Socapex RJFTV6MN	85 °C	-40 °C	Housing for Prewired RJ45 Cordset	Silver	500	Free Hanging (In-Line)	Plug Not Provided	Unshielded	IP67 - Dust Tight Waterproof	Shock Resistant Toolless Vibration Resistant
Amphenol Socapex RJFTV6A7A1G	85 °C	-40 °C				Bulkhead Panel Mount		Shielded	IP68 - Dust Tight Waterproof		8p8c (RJ45) Jack	Coupler	Aluminum Olive Drab Cadmium Plated	Cat6a	Jack 8p8c (RJ45)
Amphenol Socapex RJFTV6A7A1GF312	85 °C	-40 °C				Bulkhead Panel Mount		Shielded	IP68 - Dust Tight Waterproof		8p8c (RJ45) Jack	Coupler	Aluminum Olive Drab Cadmium Plated	Cat6a	Jack 8p8c (RJ45)
Amphenol Socapex RJFTV6MBZ	85 °C	-40 °C	Housing for Prewired RJ45 Cordset		500	Free Hanging (In-Line)	Plug Not Provided	Unshielded	IP67 - Dust Tight Waterproof	Shock Resistant Toolless Vibration Resistant						Bayonet Lock
Amphenol Socapex RJFTV6N	85 °C	-40 °C	Housing for Prewired RJ45 Cordset	Silver	500	Free Hanging (In-Line)	Plug Not Provided	Unshielded	IP67 - Dust Tight Waterproof	Shock Resistant Toolless Vibration Resistant
Amphenol Socapex RJFTV6A7SA1NF312	85 °C	-40 °C				Bulkhead Panel Mount		Shielded	IP68 - Dust Tight Waterproof		8p8c (RJ45) Jack	Coupler	Aluminum Nickel Plated	Cat6a	Jack 8p8c (RJ45)
Amphenol Socapex RJFTV6A2A1N	85 °C	-40 °C				Panel Mount Square Flange		Shielded	IP68 - Dust Tight Waterproof		8p8c (RJ45) Jack	Coupler	Aluminum Nickel Plated	Cat6a	Jack 8p8c (RJ45)

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 343.16
		10	$ 318.00
		30	$ 306.56

Description

General part information

RJFTV6 Series

Plug Housing Housing for Prewired RJ45 Cordset Modular Connector Bayonet Lock
