HW-SPAR3ADDR2-DK-UNI-G

Obsolete

AMD

KIT DEV SPARTAN 3A DDR2 SDRAM

Search across all available documentation for this part.

Obsolete

AMD

KIT DEV SPARTAN 3A DDR2 SDRAM

Technical Specifications

Parameters and characteristics for this part

Specification	HW-SPAR3ADDR2-DK-UNI-G

Contents	Board(s)
For Use With/Related Products	XC3S700A
Platform	Spartan-3A DDR2 SDRAM Interface
Utilized IC / Part	XC3S700A

Part	Mounting Type	Supplier Device Package	Number of LABs/CLBs	Operating Temperature [Min]	Operating Temperature [Max]	Package / Case	Number of Gates	Number of I/O	Number of Logic Elements/Cells	Total RAM Bits	Utilized IC / Part	For Use With/Related Products	Platform	Contents
AMD XC3S700AN-4FGG484C	Surface Mount	484-FBGA (23x23)	1472	0 °C	85 °C	484-BBGA	700000	372	13248	368640
AMD XC3S700A-4FGG484I	Surface Mount	484-FBGA (23x23)	1472	-40 C	100 °C	484-BBGA	700000	372	13248	368640
AMD XC3S700AN-4FG484I	Surface Mount	484-FBGA (23x23)	1472	-40 C	100 °C	484-BBGA	700000	372	13248	368640
AMD XC3S700A-4FG484I	Surface Mount	484-FBGA (23x23)	1472	-40 C	100 °C	484-BBGA	700000	372	13248	368640
AMD XC3S700A-4FT256I	Surface Mount	256-FTBGA (17x17)	1472	-40 C	100 °C	256-LBGA	700000	161 I/O	13248	368640
AMD HW-SPAR3AN-SK-UNI-G											XC3S700AN	XC3S700AN	Spartan-3AN FPGA Starter Kit UNI	Board(s) Cable(s) Power Supply
AMD HW-SPAR3ADDR2-DK-UNI-G											XC3S700A	XC3S700A	Spartan-3A DDR2 SDRAM Interface	Board(s)
AMD XC3S700A-5FGG484C	Surface Mount	484-FBGA (23x23)	1472	0 °C	85 °C	484-BBGA	700000	372	13248	368640
AMD XC3S700A-4FG400I	Surface Mount	400-FBGA (21x21)	1472	-40 C	100 °C	400-BGA	700000	311	13248	368640
AMD XC3S700A-4FGG400C	Surface Mount	400-FBGA (21x21)	1472	0 °C	85 °C	400-BGA	700000	311	13248	368640

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Spartan-3A DDR2 SDRAM Interface XC3S700A Spartan®-3A FPGA Evaluation Board
