60AR18-8-060C

Active

Grayhill Inc.

SWITCH JOYSTICK FLATTED 6" CBL

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

60AR18-8-060C

Active

Grayhill Inc.

SWITCH JOYSTICK FLATTED 6" CBL

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	60AR18-8-060C

Actuator Type	Flatted
Actuator Type [diameter]	6.35 mm
Current Rating (Amps)	10 mA
Ingress Protection	IP67 - Dust Tight, Waterproof
Mechanical Life	500000 Cycles
Operating Force	1500 gf
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Output	Digital (Mechanical Switch, Pulse)
Panel Cutout Dimensions [diameter]	17.25 mm
Switch Function	360° Rotational, Center Select, 8-Way Directional
Termination Style	Cable with Connector
Type	Joystick, 3 - Axis
Voltage - Supply	5 V
Voltage Rating - DC	5 V

60AR18 Series

Part	Actuator Type [diameter]	Actuator Type	Panel Cutout Dimensions [diameter]	Mechanical Life	Operating Temperature [Max]	Operating Temperature [Min]	Switch Function	Operating Force	Ingress Protection	Output	Voltage - Supply	Type	Voltage Rating - DC	Current Rating (Amps)	Termination Style
Grayhill Inc. 60AR18-4-020C	6.35 mm	Flatted	17.25 mm	500000 Cycles	85 °C	-40 °C	360° Rotational 4-Way Directional Center Select	1500 gf	IP67 - Dust Tight Waterproof	Digital (Mechanical Switch Pulse)	5 V	Joystick 3 - Axis	5 V	10 mA	Cable with Connector
Grayhill Inc. 60AR18-8-250C	6.35 mm	Flatted	17.25 mm	500000 Cycles	85 °C	-40 °C	360° Rotational 8-Way Directional Center Select	1500 gf	IP67 - Dust Tight Waterproof	Digital (Mechanical Switch Pulse)	5 V	Joystick 3 - Axis	5 V	10 mA	Cable with Connector
Grayhill Inc. 60AR18-8-040S	6.35 mm	Flatted	17.25 mm	500000 Cycles	85 °C	-40 °C	360° Rotational 8-Way Directional Center Select	1500 gf	IP67 - Dust Tight Waterproof	Digital (Mechanical Switch Pulse)	5 V	Joystick 3 - Axis	5 V	10 mA	Cable with Connector
Grayhill Inc. 60AR18-8-060C	6.35 mm	Flatted	17.25 mm	500000 Cycles	85 °C	-40 °C	360° Rotational 8-Way Directional Center Select	1500 gf	IP67 - Dust Tight Waterproof	Digital (Mechanical Switch Pulse)	5 V	Joystick 3 - Axis	5 V	10 mA	Cable with Connector
Grayhill Inc. 60AR18-8-P	6.35 mm	Flatted	17.25 mm	500000 Cycles	85 °C	-40 °C	360° Rotational 8-Way Directional Center Select	1500 gf	IP67 - Dust Tight Waterproof	Digital (Mechanical Switch Pulse)	5 V	Joystick 3 - Axis	5 V	10 mA	Cable with Connector
Grayhill Inc. 60AR18-8-025C	6.35 mm	Flatted	17.25 mm	500000 Cycles	85 °C	-40 °C	360° Rotational 8-Way Directional Center Select	1500 gf	IP67 - Dust Tight Waterproof	Digital (Mechanical Switch Pulse)	5 V	Joystick 3 - Axis	5 V	10 mA	Cable with Connector

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	25	$ 125.07

Description

General part information

60AR18 Series

Joystick, 3 - Axis Digital (Mechanical Switch, Pulse) Output
