T599B476M004ATE070

Active

KEMET

TANTALUM POLYMER CAPACITOR, 47 ΜF, ± 20%, 4 V, B, 0.07 OHM, 1411 [3528 METRIC]

Search across all available documentation for this part.

Active

KEMET

TANTALUM POLYMER CAPACITOR, 47 ΜF, ± 20%, 4 V, B, 0.07 OHM, 1411 [3528 METRIC]

Technical Specifications

Parameters and characteristics for this part

Specification	T599B476M004ATE070

Capacitance	47 µF
ESR (Equivalent Series Resistance)	70 mOhm
Features	Automotive
Height - Seated (Max) [Max] [z]	2.1 mm
Height - Seated (Max) [Max] [z]	0.083 "
Lifetime @ Temp.	2000 Hrs
Manufacturer Size Code	B
Mounting Type	Surface Mount
Operating Temperature [Max]	150 °C
Operating Temperature [Min]	-55 °C
Package / Case	1411
Package / Case	3528 Metric
Ratings	AEC-Q200
Size / Dimension [x]	0.138 "
Size / Dimension [x]	3.5 mm
Size / Dimension [y]	0.11 in
Size / Dimension [y]	2.8 mm
Tolerance	20 %
Type	Molded
Voltage - Rated	4 V

Part	Mounting Type	Lifetime @ Temp.	Ratings	Capacitance	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Tolerance	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	ESR (Equivalent Series Resistance)	Features	Type	Operating Temperature [Min]	Operating Temperature [Max]	Manufacturer Size Code	Voltage - Rated	Package / Case	Package / Case
KEMET T599B476M004ATE070	Surface Mount	2000 Hrs	AEC-Q200	47 µF	0.11 in	2.8 mm	0.138 "	3.5 mm	20 %	2.1 mm	0.083 "	70 mOhm	Automotive	Molded	-55 °C	150 °C	B	4 V	1411	3528 Metric

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Cut Tape (CT)	1	$ 1.28
	Digi-Reel®	1	$ 1.28
	Tape & Reel (TR)	2000	$ 0.38
Newark	Each (Supplied on Full Reel)	2000	$ 0.39
		4000	$ 0.35
		6000	$ 0.34
		10000	$ 0.33

General part information

47 µF Molded Tantalum Polymer Capacitor 4 V 1411 (3528 Metric) 70mOhm @ 100kHz
