KMF0.2143.11

Active

SCHURTER Inc.

CONNECTOR: AC SUPPLY; SOCKET; MALE; 4A; 250VAC; C18; KMF; IEC 60320

Search across all available documentation for this part.

Active

SCHURTER Inc.

CONNECTOR: AC SUPPLY; SOCKET; MALE; 4A; 250VAC; C18; KMF; IEC 60320

Technical Specifications

Parameters and characteristics for this part

Specification	KMF0.2143.11

Accomodates a Fuse	True
Approval Agency	ENEC, CCC, cURus
Connector Style	IEC 320-C18
Connector Type	Receptacle, Male Blades - Module
Current Rating - Appliance Inlet	10 A
Current Rating - Filter	4 A
Filter Type	Filtered (EMI, RFI) - Commercial, Medical
Fuse Holder, Drawer	Fuse Holder
Ingress Protection	IP40
Material Flammability Rating	UL94 V-0
Mounting Type	Panel Mount, Snap-In
Panel Cutout Dimensions [x]	28.8 mm
Panel Cutout Dimensions [y]	47.8 mm
Panel Thickness [Max]	2.5 mm
Panel Thickness [Max]	0.098 in
Panel Thickness [Min]	1 mm
Panel Thickness [Min]	0.039 in
Switch Features	Switch On-Off
Termination	0.189 ", 4.8 mm
Termination	Quick Connect
Voltage Rating - Appliance Inlet	250 VAC

Part	Current Rating - Appliance Inlet	Panel Thickness [Max]	Panel Thickness [Min]	Panel Thickness [Max]	Panel Thickness [Min]	Ingress Protection	Connector Type	Fuse Holder, Drawer	Connector Style	Termination	Termination	Mounting Type	Current Rating - Filter	Voltage Rating - Appliance Inlet	Approval Agency	Material Flammability Rating	Switch Features	Panel Cutout Dimensions [y]	Panel Cutout Dimensions [x]	Filter Type	Accomodates a Fuse	Features
SCHURTER Inc. KMF0.2143.11	10 A	2.5 mm	1 mm	0.098 in	0.039 in	IP40	Receptacle Male Blades - Module	Fuse Holder	IEC 320-C18	0.189 " 4.8 mm	Quick Connect	Panel Mount Snap-In	4 A	250 VAC	CCC cURus ENEC	UL94 V-0	Switch On-Off	47.8 mm	28.8 mm	Filtered (EMI RFI) - Commercial Medical
SCHURTER Inc. KMF1.1243.11	10 A	2.5 mm	1 mm	0.098 in	0.039 in	IP40	Receptacle Male Blades - Module	Drawer Sold Separate	IEC 320-C14	0.189 " 4.8 mm	Quick Connect	Panel Mount Snap-In	4 A	250 VAC	CCC cULus ENEC	UL94 V-0	Switch On-Off	47.8 mm	28.8 mm	Filtered (EMI RFI) - Commercial Medical		Shielded

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Power Entry Connector Receptacle, Male Blades - Module IEC 320-C18 Panel Mount, Snap-In
