MS27467E21B11SA

Active

Corsair

PLUG STRAIGHT CABLE

Search across all available documentation for this part.

Active

Corsair

PLUG STRAIGHT CABLE

Technical Specifications

Parameters and characteristics for this part

Specification	MS27467E21B11SA

Applications	Military, Aerospace
Color	Olive Drab
Connector Type	Female Sockets, Plug
Contact Finish - Mating	Gold
Fastening Type	Bayonet Lock
Features	Coupling Nut
Grade	Military
Ingress Protection	IP67
Insert Material	Thermoplastic
Material Flammability Rating	UL94 V-0
Mounting Type	Free Hanging (In-Line)
Number of Positions	11
Operating Temperature [Max]	200 °C
Operating Temperature [Min]	-65 ░C
Orientation	A
Primary Material	Metal
Qualification	MIL-DTL-38999 Series I
Shell Size - Insert	21-11
Shell Size, MIL	F
Shielding	Shielded
Termination	Crimp

Part	Shell Size, MIL	Applications	Color	Material Flammability Rating	Termination	Ingress Protection	Grade	Shielding	Operating Temperature [Min]	Operating Temperature [Max]	Orientation	Qualification	Contact Finish - Mating	Connector Type	Number of Positions	Features	Fastening Type	Mounting Type	Insert Material	Shell Size - Insert [Min]	Shell Size - Insert [Max]	Primary Material	Shell Size - Insert
Corsair MS27467E21B35PA	F	Aerospace Military	Olive Drab	UL94 V-0	Crimp	IP67	Military	Shielded	-65 ░C	200 °C	A	MIL-DTL-38999 Series I	Gold	Male Pins Plug	79	Coupling Nut	Bayonet Lock	Free Hanging (In-Line)	Thermoplastic	21	35	Metal
Corsair MS27467E21B11SA	F	Aerospace Military	Olive Drab	UL94 V-0	Crimp	IP67	Military	Shielded	-65 ░C	200 °C	A	MIL-DTL-38999 Series I	Gold	Female Sockets Plug	11	Coupling Nut	Bayonet Lock	Free Hanging (In-Line)	Thermoplastic			Metal	21-11

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

11 Position Circular Connector Plug, Female Sockets Crimp
