T591B107M004ATE055

Active

KEMET

CAP, 100UF, 4V, TANT, POLYMER, CASE B ROHS COMPLIANT: YES

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsT591B107M004ATE055 Spec Datasheet +2

T591B107M004ATE055

Active

KEMET

CAP, 100UF, 4V, TANT, POLYMER, CASE B ROHS COMPLIANT: YES

Deep-Dive with AI

DocumentsT591B107M004ATE055 Spec Datasheet +2

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	T591B107M004ATE055

Capacitance	100 µF
ESR (Equivalent Series Resistance)	55 mOhm
Features	General Purpose
Height - Seated (Max) [Max] [z]	2.1 mm
Height - Seated (Max) [Max] [z]	0.083 "
Lifetime @ Temp.	2000 Hrs
Manufacturer Size Code	B
Mounting Type	Surface Mount
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 °C
Package / Case	1411
Package / Case	3528 Metric
Size / Dimension [x]	0.138 "
Size / Dimension [x]	3.5 mm
Size / Dimension [y]	0.11 in
Size / Dimension [y]	2.8 mm
Tolerance	20 %
Type	Molded
Voltage - Rated	4 V

T591B Series

Part	Mounting Type	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Features	Voltage - Rated	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Lifetime @ Temp.	Operating Temperature [Min]	Operating Temperature [Max]	Manufacturer Size Code	ESR (Equivalent Series Resistance)	Capacitance	Tolerance	Package / Case	Package / Case	Type
KEMET T591B226M006ATE070	Surface Mount	0.11 in	2.8 mm	0.138 "	3.5 mm	General Purpose	6.3 V	2.1 mm	0.083 "	2000 Hrs	-55 °C	125 °C	B	70 mOhm	22 µF	20 %	1411	3528 Metric	Molded
KEMET T591B107M006ATE0707280	Surface Mount	0.11 in	2.8 mm	0.138 "	3.5 mm	General Purpose	6.3 V	2.1 mm	0.083 "	2000 Hrs	-55 °C	125 °C	B	70 mOhm	100 µF	20 %	1411	3528 Metric	Molded
KEMET T591B157M006ATE070	Surface Mount	0.11 in	2.8 mm	0.138 "	3.5 mm	General Purpose	6.3 V	2.1 mm	0.083 "	2000 Hrs	-55 °C	125 °C	B	70 mOhm	150 µF	20 %	1411	3528 Metric	Molded
KEMET T591B475M035ATE200	Surface Mount	0.11 in	2.8 mm	0.138 "	3.5 mm	General Purpose	35 V	2.1 mm	0.083 "	1000 Hrs	-55 °C	125 °C	B	200 mOhm	4.7 µF	20 %	1411	3528 Metric	Molded
KEMET T591B476M010ATE070	Surface Mount	0.11 in	2.8 mm	0.138 "	3.5 mm	General Purpose	10 V	2.1 mm	0.083 "	2000 Hrs	-55 °C	125 °C	B	70 mOhm	47 µF	20 %	1411	3528 Metric	Molded
KEMET T591B336M010ATE070	Surface Mount	0.11 in	2.8 mm	0.138 "	3.5 mm	General Purpose	10 V	2.1 mm	0.083 "	2000 Hrs	-55 °C	125 °C	B	70 mOhm	33 ÁF	20 %	1411	3528 Metric	Molded
KEMET T591B107M006ATE070	Surface Mount	0.11 in	2.8 mm	0.138 "	3.5 mm	General Purpose	6.3 V	2.1 mm	0.083 "	2000 Hrs	-55 °C	125 °C	B	70 mOhm	100 µF	20 %	1411	3528 Metric	Molded
KEMET T591B107M004ATE0707280	Surface Mount	0.11 in	2.8 mm	0.138 "	3.5 mm	General Purpose	4 V	2.1 mm	0.083 "	2000 Hrs	-55 °C	105 ░C	B	70 mOhm	100 µF	20 %	1411	3528 Metric	Molded
KEMET T591B107M004ATE045	Surface Mount	0.11 in	2.8 mm	0.138 "	3.5 mm	General Purpose	4 V	2.1 mm	0.083 "	2000 Hrs	-55 °C	125 °C	B	45 mOhm	100 µF	20 %	1411	3528 Metric	Molded
KEMET T591B107M004ATE055	Surface Mount	0.11 in	2.8 mm	0.138 "	3.5 mm	General Purpose	4 V	2.1 mm	0.083 "	2000 Hrs	-55 °C	125 °C	B	55 mOhm	100 µF	20 %	1411	3528 Metric	Molded

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tape & Reel (TR)	2000	$ 0.41
Newark	Each (Supplied on Cut Tape)	10	$ 1.05
		25	$ 0.96
		50	$ 0.88
		100	$ 0.81
		250	$ 0.69
		500	$ 0.62

Description

General part information

T591B Series

100 µF Molded Tantalum Polymer Capacitor 4 V 1411 (3528 Metric) 55mOhm @ 100kHz
