MP5016HGQH-Z
ActiveMONOLITHIC POWER SYSTEMS (MPS)
IC PWR LMT SWITCH N-CH 1:1 10QFN
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
MP5016HGQH-Z
ActiveMONOLITHIC POWER SYSTEMS (MPS)
IC PWR LMT SWITCH N-CH 1:1 10QFN
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | MP5016HGQH-Z |
|---|---|
| Current - Output (Max) [Max] | 5 A |
| Fault Protection | Over Current, Over Voltage |
| Features | Slew Rate Controlled |
| Interface | On/Off |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 125 ¯C |
| Operating Temperature [Min] | -40 °C |
| Output Configuration | High Side |
| Output Type | N-Channel |
| Package / Case | 10-PowerVFQFN |
| Ratio - Input:Output [custom] | 1:1 |
| Rds On (Typ) | 43 mOhm |
| Supplier Device Package | 10-QFN |
| Supplier Device Package [x] | 1.5 |
| Supplier Device Package [y] | 2 |
| Switch Type | General Purpose |
| Voltage - Supply (Vcc/Vdd) [Max] | 22 V |
| Voltage - Supply (Vcc/Vdd) [Min] | 2.7 V |
