AR01DTD1181
ActiveViking Technology
RES 1.18K OHM 0.5% 1/32W 0201
Deep-Dive with AI
Search across all available documentation for this part.
AR01DTD1181
ActiveViking Technology
RES 1.18K OHM 0.5% 1/32W 0201
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | AR01DTD1181 |
|---|---|
| Composition | Thin Film |
| Height - Seated (Max) [Max] | 0.28 mm |
| Height - Seated (Max) [Max] | 0.011 " |
| Number of Terminations | 2 |
| Operating Temperature [Max] | 155 °C |
| Operating Temperature [Min] | -55 °C |
| Package / Case | 0603 Metric |
| Package / Case | 0201 |
| Power (Watts) | 0.03125 W |
| Power (Watts) | 30 mW |
| Resistance | 1.18 kOhms |
| Size / Dimension [x] | 0.023 " |
| Size / Dimension [x] | 0.58 mm |
| Size / Dimension [y] | 0.011 in |
| Size / Dimension [y] | 0.29 mm |
| Supplier Device Package | 0201 |
| Temperature Coefficient | 50 ppm/°C |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tape & Reel (TR) | 1 | $ 0.01 | |
Description
General part information
AR01DTD Series
1.18 kOhms ±0.5% 0.03W, 1/32W Chip Resistor 0201 (0603 Metric) Thin Film
Documents
Technical documentation and resources
No documents available
