Technical Specifications
Parameters and characteristics for this part
| Specification | SNCV5700DR2G |
|---|---|
| Channel Type | Synchronous |
| Current - Peak Output (Source, Sink) [custom] | 6.8 A |
| Current - Peak Output (Source, Sink) [custom] | 7.8 A |
| Driven Configuration | High-Side, Low-Side |
| Gate Type | IGBT |
| Input Type | Inverting |
| Logic Voltage - VIL, VIH [custom] | 4.3 V |
| Logic Voltage - VIL, VIH [custom] | 0.75 V |
| Mounting Type | Surface Mount |
| Number of Drivers | 2 |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 16-SOIC |
| Package / Case [x] | 0.154 in |
| Package / Case [y] | 3.9 mm |
| Rise / Fall Time (Typ) [custom] | 7.9 ns |
| Rise / Fall Time (Typ) [custom] | 9.2 ns |
| Supplier Device Package | 16-SOIC |
| Voltage - Supply [Max] | 20 V |
| Voltage - Supply [Min] | 12.5 V |
