57125-501
ActiveLaird Thermal Systems, Inc.
PELTIER MODULE CP2,31,06,L1,W4.5
Deep-Dive with AI
Search across all available documentation for this part.
57125-501
ActiveLaird Thermal Systems, Inc.
PELTIER MODULE CP2,31,06,L1,W4.5
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 57125-501 |
|---|---|
| Current - Max [Max] | 14 A |
| Delta Tmax @ Th | 68 °C |
| Features | Lead Wires, Non-Sealed |
| Height [z] | 4.57 mm |
| Number of Stages | 1 |
| Operating Temperature | 80 °C |
| Qmax @ Th | 29.3 W |
| Resistance | 0.23 Ohms |
| Size / Dimension [x] | 29.72 mm |
| Size / Dimension [y] | 29.72 mm |
| Voltage - Max [Max] | 3.5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 17.53 | |
| 5 | $ 17.44 | |||
Description
General part information
57125 Series
Peltier Module 29.3W @ 25°C 14 A 80°C
Documents
Technical documentation and resources
