MC74AC05M

Active

Motorola

IC INVERTER 6CH 1-INP 14SOIC

Search across all available documentation for this part.

Active

Motorola

IC INVERTER 6CH 1-INP 14SOIC

Technical Specifications

Parameters and characteristics for this part

Specification	MC74AC05M

Current - Output High, Low	24 mA
Current - Quiescent (Max) [Max]	4 µA
Features	Open Drain
Input Logic Level - High [Max]	3.85 V
Input Logic Level - High [Min]	2.1 V
Input Logic Level - Low [Max]	1.65 V
Input Logic Level - Low [Min]	0.9 V
Logic Type	Inverter
Max Propagation Delay @ V, Max CL	6 ns
Mounting Type	Surface Mount
Number of Circuits	6
Number of Inputs	1
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Package / Case	14-SOIC
Package / Case [x]	0.209 "
Package / Case [y]	5.3 mm
Voltage - Supply [Max]	6 V
Voltage - Supply [Min]	2 V

Part	Logic Type	Number of Circuits	Input Logic Level - High [Min]	Input Logic Level - High [Max]	Input Logic Level - Low [Max]	Input Logic Level - Low [Min]	Package / Case [x]	Package / Case	Package / Case [y]	Number of Inputs	Operating Temperature [Max]	Operating Temperature [Min]	Max Propagation Delay @ V, Max CL	Mounting Type	Current - Output High, Low	Features	Voltage - Supply [Min]	Voltage - Supply [Max]	Current - Quiescent (Max) [Max]
Motorola MC74AC05M	Inverter	6	2.1 V	3.85 V	1.65 V	0.9 V	0.209 "	14-SOIC	5.3 mm	1	85 °C	-40 °C	6 ns	Surface Mount	24 mA	Open Drain	2 V	6 V	4 µA

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	2049	$ 0.15

General part information

Inverter IC 6 Channel Open Drain 14-SOIC
