XBC-V1-UT-001
ObsoleteDigi
RF TXRX MOD CELL U.FL TH
Deep-Dive with AI
Search across all available documentation for this part.
XBC-V1-UT-001
ObsoleteDigi
RF TXRX MOD CELL U.FL TH
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | XBC-V1-UT-001 |
|---|---|
| Antenna Type | Antenna Not Included, U.FL |
| Current - Receiving | 530 mA |
| Current - Transmitting | 860 mA |
| Modulation | QPSK |
| Mounting Type | Through Hole |
| Operating Temperature [Max] | 80 C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | Module |
| Power - Output | 23 dBmW |
| Protocol | 4G LTE CAT-1 (Verizon) |
| RF Family/Standard | Cellular |
| Sensitivity | -102 dBm |
| Serial Interfaces | UART |
| Voltage - Supply [Max] | 5.5 V |
| Voltage - Supply [Min] | 3 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
XBC-V1 Series
Cellular 4G LTE CAT-1 (Verizon) Transceiver Module Antenna Not Included, U.FL Through Hole
