NFMJMPC226R0G3D
ActiveMurata Power Solutions Inc.
05035 (1209M) 4VDC 22UF +- 20%
Deep-Dive with AI
Search across all available documentation for this part.
NFMJMPC226R0G3D
ActiveMurata Power Solutions Inc.
05035 (1209M) 4VDC 22UF +- 20%
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | NFMJMPC226R0G3D |
|---|---|
| Capacitance | 22 µF |
| Current | 2 A |
| DC Resistance (DCR) (Max) [Max] | 30 mOhm |
| Height (Max) | 0.8 mm |
| Height (Max) [Max] | 0.032 " |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 105 ░C |
| Operating Temperature [Min] | -55 °C |
| Package / Case | 0504 (1210 Metric) |
| Size / Dimension [x] | 1.2 mm |
| Size / Dimension [x] | 0.047 in |
| Size / Dimension [y] | 0.9 mm |
| Size / Dimension [y] | 0.035 in |
| Tolerance | 20 % |
| Voltage - Rated | 4 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 0.15 | |
| 10 | $ 0.14 | |||
| 25 | $ 0.14 | |||
| 50 | $ 0.14 | |||
| 100 | $ 0.13 | |||
| 250 | $ 0.11 | |||
| 500 | $ 0.08 | |||
| 1000 | $ 0.08 | |||
| 5000 | $ 0.07 | |||
| Digi-Reel® | 1 | $ 0.15 | ||
| 10 | $ 0.14 | |||
| 25 | $ 0.14 | |||
| 50 | $ 0.14 | |||
| 100 | $ 0.13 | |||
| 250 | $ 0.11 | |||
| 500 | $ 0.08 | |||
| 1000 | $ 0.08 | |||
| 5000 | $ 0.07 | |||
| Tape & Reel (TR) | 10000 | $ 0.07 | ||
| 30000 | $ 0.06 | |||
Description
General part information
NFMJMPC Series
22 µF Feed Through Capacitor 4V 2 A 30mOhm 0504 (1210 Metric)
Documents
Technical documentation and resources
