1532-B-6-B-12

Active

RAF Electronic Hardware

1/4 RD X 3/16 X .140 ID

Search across all available documentation for this part.

Active

RAF Electronic Hardware

1/4 RD X 3/16 X .140 ID

Technical Specifications

Parameters and characteristics for this part

Part	Threaded/Unthreaded	Color	Diameter - Outside [diameter]	Diameter - Outside [diameter]	Diameter - Outside [diameter]	Length - Overall [x]	Length - Overall [x]	Diameter - Inside [diameter]	Diameter - Inside [diameter]	Type	Gender	Material	Plating	Between Board Height	Between Board Height	Between Board Height
RAF Electronic Hardware 1532-B-4-AL-7	Unthreaded	Clear	6.35 mm	0.25 in	0.25 in	0.293 in	7.43 mm	0.115 in	2.92 mm	Round Spacer	Female Swage	Aluminum	Iridite	0.188 "	4.78 mm	0.1875 "
RAF Electronic Hardware 1532-B-6-B-5	Unthreaded		6.35 mm	0.25 in	0.25 in	0.293 in	7.44 mm	0.14 in	3.56 mm	Round Spacer	Female Swage	Brass	Nickel	0.188 "	4.78 mm	0.1875 "
RAF Electronic Hardware 1532-B-6-B-12	Unthreaded	Clear	6.35 mm	0.25 in	0.25 in	0.293 in	7.43 mm	0.14 in	3.56 mm	Round Spacer	Female Swage	Brass	Chromate Zinc	0.188 "	4.78 mm	0.1875 "
RAF Electronic Hardware 1532-B-6-AL-22	Unthreaded	Clear	6.35 mm	0.25 in	0.25 in	0.293 in	7.43 mm	0.14 in	3.56 mm	Round Spacer	Female Swage	Aluminum	Anodized	0.188 "	4.78 mm	0.1875 "

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Round Spacer Unthreaded Brass 0.188" (4.78mm) 3/16" Clear

Technical documentation and resources

No documents available
