T9AV5D22-18

Obsolete

TE Connectivity Potter & Brumfield Relays

RELAY GEN PURPOSE SPDT 20A 18V

Deep-Dive with AI

Search across all available documentation for this part.

T9AV5D22-18

Obsolete

TE Connectivity Potter & Brumfield Relays

RELAY GEN PURPOSE SPDT 20A 18V

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	T9AV5D22-18

Coil Insulation	Class F
Coil Resistance	324 Ohms
Coil Type	Non Latching
Coil Voltage	18 VDC
Contact Form	SPDT (1 Form C)
Contact Material	Silver Cadmium Oxide (AgCdO)
Contact Rating (Current)	20 A
Load - Max Switching	5540 VA
Mounting Type	Through Hole
Must Operate Voltage	13.5 VDC
Must Release Voltage	1.8 VDC
Operate Time	15 ms
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-55 °C
Relay Type	General Purpose
Release Time	15 ms
Seal Rating	Sealed - Flux Protection
Switching Voltage [Max]	277 VAC
Termination Style	PC Pin, Quick Connect
Termination Style	0.25 in

T9AV5 Series

Part	Coil Insulation	Coil Current	Relay Type	Coil Resistance	Must Operate Voltage	Contact Rating (Current)	Must Release Voltage	Release Time	Load - Max Switching	Contact Form	Termination Style	Termination Style	Operating Temperature [Max]	Operating Temperature [Min]	Switching Voltage [Max]	Coil Type	Mounting Type	Seal Rating	Contact Material	Operate Time	Coil Voltage
TE Connectivity Potter & Brumfield Relays T9AV5D22-22	Class F	45.5 mA	General Purpose	484 Ohms	16.5 VDC	20 A	2.2 VDC	15 ms	5540 VA	SPDT (1 Form C)	PC Pin Quick Connect	0.25 in	85 °C	-55 °C	277 VAC	Non Latching	Through Hole	Sealed - Flux Protection	Silver Cadmium Oxide (AgCdO)	15 ms	22 VDC
TE Connectivity Potter & Brumfield Relays T9AV5D22-22-03	Class F		General Purpose		16.5 VDC	20 A	2.2 VDC	15 ms	5540 VA	SPDT (1 Form C)	PC Pin Quick Connect	0.25 in	85 °C	-55 °C	277 VAC	Non Latching	Through Hole	Sealed - Flux Protection	Silver Cadmium Oxide (AgCdO)	15 ms	22 VDC
TE Connectivity Potter & Brumfield Relays T9AV5D22-18	Class F		General Purpose	324 Ohms	13.5 VDC	20 A	1.8 VDC	15 ms	5540 VA	SPDT (1 Form C)	PC Pin Quick Connect	0.25 in	85 °C	-55 °C	277 VAC	Non Latching	Through Hole	Sealed - Flux Protection	Silver Cadmium Oxide (AgCdO)	15 ms	18 VDC
TE Connectivity Potter & Brumfield Relays 1419137-2	Class F	41.7 mA	General Purpose	576 Ohms	18 VDC	20 A	2.4 VDC	15 ms		SPDT (1 Form C)	PC Pin Quick Connect	0.25 in	85 °C	-55 °C	277 VAC	Non Latching	Through Hole	Sealed - Flux Protection	Silver Cadmium Oxide (AgCdO)	15 ms	24 VDC
TE Connectivity Potter & Brumfield Relays T9AV5D22-24	Class F	41.7 mA	General Purpose	576 Ohms	18 VDC	20 A	2.4 VDC	15 ms	5540 VA	SPDT (1 Form C)	PC Pin Quick Connect	0.25 in	85 °C	-55 °C	277 VAC	Non Latching	Through Hole	Sealed - Flux Protection	Silver Cadmium Oxide (AgCdO)	15 ms	24 VDC
TE Connectivity Potter & Brumfield Relays T9AV5L12-9-01	Class F	93 mA	General Purpose	97 Ohms	6.75 VDC	20 A	0.9 VDC	15 ms	5540 VA	SPDT (1 Form C)	PC Pin		85 °C	-55 °C	277 VAC	Non Latching	Through Hole	Sealed - Flux Protection	Silver Cadmium Oxide (AgCdO)	15 ms	9 VDC
TE Connectivity Potter & Brumfield Relays T9AV5D12-22	Class F		General Purpose		16.5 VDC	20 A	2.2 VDC	15 ms	5540 VA	SPDT (1 Form C)	PC Pin		85 °C	-55 °C	277 VAC	Non Latching	Through Hole	Sealed - Flux Protection	Silver Cadmium Oxide (AgCdO)	15 ms	22 VDC

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Description

General part information

T9AV5 Series

General Purpose Relay SPDT (1 Form C) 18VDC Coil Through Hole
