DS1200DC-3-005

Active

ARTESYN / Advanced Energy

DC/DC CONVERTER 12V 1200W

Search across all available documentation for this part.

Active

ARTESYN / Advanced Energy

DC/DC CONVERTER 12V 1200W

Technical Specifications

Parameters and characteristics for this part

Specification	DS1200DC-3-005

Applications	ITE (Commercial)
Approval Agency	CE, EN60950, NEMKO, cUL, UL, CCC
Current - Output (Max) [Max]	100 A
Efficiency	91 %
Mounting Type	Rack Mount
Number of Outputs	1
Operating Temperature [Max] [custom]	50 °C
Operating Temperature [Min] [custom]	-10 °C
Power (Watts)	1200 W
Size / Dimension [x]	279.4 mm
Size / Dimension [x]	11 in
Size / Dimension [y]	81.3 mm
Size / Dimension [y]	3.2 in
Size / Dimension [z]	1.57 "
Size / Dimension [z]	39.9 mm
Type	Front End
Voltage - Input (Max) [Max]	-72 V
Voltage - Input (Min) [Min]	-40 V
Voltage - Output 1	12 V

Part	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Applications	Features	Minimum Load Required	Approval Agency	Current - Output 1	Voltage - Output 1	Efficiency	Number of Outputs	Mounting Type	Operating Temperature [Min]	Operating Temperature [Max]	Power (Watts)	Voltage - Input [Max]	Voltage - Input [Min]	Type	Operating Temperature [Min] [custom]	Operating Temperature [Max] [custom]	Current - Output (Max) [Max]	Voltage - Input (Max) [Max]	Voltage - Input (Min) [Min]
ARTESYN / Advanced Energy DS1200HE-3	1.57 "	81.3 mm	279.4 mm	39.9 mm	11 in	3.2 in	ITE (Commercial)	Hot Swappable I2C Interface Load Sharing PFC PMBus™ Remote Sense Standby Output Universal Input		CE	100 A	12 V	91 %	1	Rack Mount	-10 °C	70 °C	1200 W	140 VAC 264 VAC	90 VAC 180 VAC	Front End
ARTESYN / Advanced Energy DS1200DC-3-005	1.57 "	81.3 mm	279.4 mm	39.9 mm	11 in	3.2 in	ITE (Commercial)			CCC CE cUL EN60950 NEMKO UL		12 V	91 %	1	Rack Mount			1200 W			Front End	-10 °C	50 °C	100 A	-72 V	-40 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	48	$ 553.84

General part information

Front End DC DC Converter 1 Output 12V 100A -72V Input
