C091 11C007 000 2

Active

Amphenol Tuchel Industrial

CONN RCPT HSNG MALE 7POS PNL MNT

Search across all available documentation for this part.

Active

Amphenol Tuchel Industrial

CONN RCPT HSNG MALE 7POS PNL MNT

Technical Specifications

Parameters and characteristics for this part

Specification	C091 11C007 000 2

Connector Type	Receptacle Housing
Contact Shape	Circular
Contact Size	1.5 mm
Contact Type	Crimp
Housing Color	Silver
Ingress Protection	IP69K, IP65, IP67
Insert Material	Thermoplastic
Material Flammability Rating	UL94 V-0
Mounting Feature	Bulkhead - Front Side Nut
Note	Contacts Not Included
Number of Positions	7
Operating Temperature [Max]	100 °C
Operating Temperature [Min]	-40 °C
Orientation	Keyed
Shell Finish	Nickel
Shell Material	Die Cast
Shell Size - Insert	M16-7
Shielding	Shielded
Type	For Male Pins

Part	Housing Color	Orientation	Shielding	Contact Shape	Shell Finish	Shell Material	Shell Size - Insert	Insert Material	Mounting Feature	Note	Type	Connector Type	Number of Positions	Operating Temperature [Max]	Operating Temperature [Min]	Material Flammability Rating	Contact Size	Contact Type	Ingress Protection
Amphenol Tuchel Industrial C091 11C007 000 2	Silver	Keyed	Shielded	Circular	Nickel	Die Cast	M16-7	Thermoplastic	Bulkhead - Front Side Nut	Contacts Not Included	For Male Pins	Receptacle Housing	7	100 °C	-40 °C	UL94 V-0	1.5 mm	Crimp	IP65 IP67 IP69K

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	100	$ 7.32

General part information

7 Position Circular Connector Receptacle Housing Panel Mount
